Relaying 450 Edwardian Hallway Tiles in a Crouch-End

Pictures below of an original Edwardian Tiled Hallway at a house in Crouch End, North London. Victorian and Edwardian properties are quite common in the area which actually dates to the 13th Century and is often used in the filming of East Enders.

We were called in to look at restoring the floor back to its former glory and when inspecting and surveying the floor we found large sections of tiles that were loose and three doorway thresholds that required rebuilding and re-tiling. If you have been following our website posts, you will know this is something we specialise in, so we were more than happy to help.

Edwardian Hallway Threshold Before Restoration Crouch End

Restoring an Edwardian Tiled Floor

Before cleaning the floor our first task was to remove the loose, damaged, cracked and broken tiles. These were set aside and those that could be re-used were cleaned prior to re-laying. The remaining tiles were then cleaned using Tile Doctor Remove & Go to remove the old waxes and seals.

Edwardian Hallway Floor Before Restoration Crouch End

Over the course of three days we worked in small areas of about a metre square at a time. After cleaning the tiles were then fully rinsed and steam cleaned and left to dry. In the meantime, we began the repairs to the thresholds and central part of the floor.

After the installation of the new and reclaimed tiles the floor was re grouted using Mapei grey grout and thoroughly cleaned and left to dry overnight.

Sealing Edwardian Style Tiles

We returned the next day to seal the floor, first checking to ensure the tiles had dried out overnight. To start the sealing we applied a single coat of Tile Doctor Colour Grow and left it to dry. Colour Grow is an impregnating sealer that provides stain protection whilst enriching the colour of the tiles in the process.

Edwardian Hallway Threshold During Sealing Crouch End

Once the first coat was dry it was followed by the application of six coats of Tile Doctor Seal & Go which is a protective Satin Seal that gives a rich, natural appearance and works really well on Victorian and Edwardian tiles.

Edwardian Hallway Threshold After Restoration Crouch End

In total the work took four days to complete and we relayed around 450 tiles in the process. Before leaving we advised our customer on how best to maintain the appearance and increase longevity of the sealer.

Edwardian Hallway Floor After Restoration Crouch End



Source: Edwardian Tile Cleaning and Maintenance Service in Crouch End, North London

Victorian Tiled Hallway Renovated in Oxford

The Victorian tiled hallway shown below had until recently been covered by carpet and was in surprisingly good condition for its age which is a testament to the durability of these floors. My client who lives in Oxford had managed to remove most of the glue that had been used to secure the carpet to the tile but found it had left an imprint on the floor. Unable to take the restoration any further we were asked to remove the ground in grime and seal the floor.

Carpet Covered Victorian Tiled Floor Before Cleaning Oxford

Restoring Victorian Quarry Tiles

My first task was to remove what was left of the carpet adhesive primarily with the aid of scraper which was used carefully along the edges. This removed the thicker parts of the glue but needed more work to remove all the traces; so a 50 grit disc fitted to a handheld machine was run around the edges of the whole floor to complete the job removing the residue and dirt in the process.

I then used a 50 grit milling pad attached to a rotary floor machine to remove the ground in grime and clean the whole floor. The floor was then rinsed with water to remove the soil that was generated afterwards and then the process repeated this with a 100 grit and 200 grit milling pad to fully restore the appearance of the tile.

This process took up most of the day so before leaving I gave the floor an acid wash using a mild dilution of Tile Doctor Grout Clean-up and then followed this with a good rinse and final clean with Tile Doctor Neutral Cleaner.

Sealing Victorian Tiles

Having finished cleaning the floor I left it to dry off completely for three days to ensure it was bone dry before returning to seal it.

To seal I applied Tile Doctor Colour Grow which is an impregnating sealer that protects the tile from within by occupying the pores in the clay, it also enhances the natural colours in the tile in the process and leaves a matt finish.

Carpet Covered Victorian Tiled Floor After Cleaning Oxford

The finished floor looks a lot brighter now it’s now free of all the dirt and glue marks, the new sealer will also ensure it’s easy to clean and keeps its appearance for some time to come.


Source: Victorian Tile Cleaning and Sealing Service in Oxfordshire

Classic but Neglected Victorian Tiled Hallway Restored in Norwich Norfolk

There are thousands of Victorian tiled hallways in and around Norwich and I often get called to work on them, however this was a particularly abused and neglected example I thought you might find interesting. The surface had clearly been both painted red at some point (possibly with an old lead-based paint) and then completely covered with rubber-backed underlay and carpeted, a thick layer of double-sided carpet tape remaining firmly stuck in patches around all the edges of the floor area.

Victorian Hallway Floor Tiles Before Cleaning Norwich

Cleaning a Victorian tiled floor

Firstly, we cleaned the whole area using a strong solution (1:3) of Tile Doctor Pro-Clean, which is a high alkaline stripper and cleaner, agitated with a black scrubbing pad fitted to a rotary machine. All products and slurry were then power rinsed and vacuumed away to reveal the improved floor.

There were still a significant number of glue patches and paint spots around the edges of the floor, so these were tackled using Tile Doctor Remove & Go, which softened them enough to enable us to remove them with a sharp-bladed scraper.

Unfortunately, the decaying rubber underlay had left a pattern on the tile surface which was most obvious at the doorway into the terracotta tiled kitchen. We almost completely removed this using Tile Doctor Oxy-Gel which being in gel form allows it work on the problem area longer. It was painted on a brush and kept moist for two hours under a layer of cling film which drew out virtually all the contaminant from the tile.

The next concern was that an original Victorian floor of this age would almost certainly have no damp proof membrane and an area near the front door which showed evidence of efflorescence salts was treated with Tile Doctor Acid Gel in order to remove the white deposits and further inhibit the production of more in the future.

The whole area was then lightly buffed using the rotary machine and a 1500 grit diamond pad with water in order to remove any remaining fine paint spots and restore a silky feel to the surface of the tiles before leaving the floor to dry overnight with assistance from our dehumidifier.

Sealing a Victorian tiled floor

When we returned the following morning, our damp meter showed us that the moisture content in the substrate was probably going to be too high to allow us to use an acrylic sealer to provide the sheen which the client had requested; so we decided to spray-buff the floor using a 3000 grit diamond pad on the rotary machine followed by the application of Tile Doctor Colour Grow, a colour enhancing penetrating sealer which sits just below the surface of the tile and leaves no visible finish. Finally, the whole floor was spray buffed to a low sheen with a white maintenance pad on the rotary machine and any resulting dust vacuumed away.

Victorian Hallway Floor Tiles After Cleaning Norwich

The Victorian tiles now look fantastic and have become a great asset to the property as original features like these are very sought after.


Source: Victorian Tile Cleaning and Restoration Service in Norwich, Norfolk

Full Restoration of a Victorian Tiled Hallway in Dudley

It may sound impossible to restore tiles that are over a century old back to something resembling their original condition but in fact it’s something we do all the time. With the right cleaning products and techniques, fantastic results can be achieved.

An example being this work I did for a customer in Dudley. They had seen previous examples of Tile Doctor’s work and wanted to have their 128-year old Victorian tiled hallway which had been covered in carpet previous restored to its best possible condition. Dudley is a town in the West Midlands that is often touted as one of the birthplaces of the Industrial Revolution so there are lot of period houses.

Victorian Tiled Hallway Floor Before Cleaning Dudley Victorian Tiled Hallway Floor Before Cleaning Dudley

When I first went over to survey the floor I could see that restoring these Victorian tiles would be a significant job involving deep cleaning, tile repair and sealing. Upon closer inspection of the tiles, I realised that there was also a small area that met the hallway which was actually Terrazzo. This was to be cleaned and sealed too however I’ll deal with that in a separate post as the process was different.

Victorian Tiled Hallway Floor Before Cleaning Dudley

Cleaning Original Victorian Tiles

To start the restoration, I treated the floor with Tile Doctor Pro-Clean which is a strong alkaline tile and grout cleaner, leaving it to dwell for a short period to start breaking down the heavy soil build-up.

Victorian Tiled Hallway Floor During Cleaning Dudley Victorian Tiled Hallway Floor During Cleaning Dudley

While the Pro-Clean was soaking into the tile, I carefully scraped off the paint that had been dropped on the tiles during decorating at some point in the past. Next, I fitted a rotary machine with a 200-grit diamond encrusted burnishing pad – which is very coarse – and put it into action to remove deeply ingrained dirt from the tiles.

When this process was complete, the floor was thoroughly rinsed with water and the resulting slurry was soaked up with the aid of a wet vacuum. I repeated this process around the edges of the hallway, where the tiles were particularly badly ingrained with dirt and marked with carpet glue deposits. The floor was given a final rinse with water and the wet vacuum used again to remove as much moisture from the floor as possible before leaving it to dry off overnight.

Before leaving however I had to complete the tiler repairs which involved removing the loose tile and mortar and then setting them back into place. There was also quite a lot of re-grouting that needed to be done on various areas of the floor.

Sealing Original Victorian Tiles

The next day, I returned to the property and ran damp tests in various places to ensure the tiles had dried. Given that these tiles are particularly old, I was conscious that that the floor very likely lacked a damp proof membrane and so damp issues could be a real possibility. We always ensure that floors are completely dry before sealing them as excess moisture can damage the performance of the sealer.

Thankfully, the tiles had dried out and, so I was able to start sealing them with four coats of Tile Doctor Seal & Go which added a nice sheen finish and will protect the floor going forward.

Victorian Tiled Hallway Floor After Cleaning Dudley Victorian Tiled Hallway Floor After Cleaning Dudley

Before leaving I left the customer with a bottle of Neutral pH tile cleaner to help maintain the tiles appearance. The customer was very happy with the results and commented that all the hard work had paid off to leave the floors looking great!

Victorian Tiled Hallway Floor After Cleaning Dudley



Source: Victorian Tile Cleaning and Restoration Service in West Midlands

Full Restoration and Repair of a Victorian Tiled Hallway Floor in Brixton

I was asked to look at an old Victorian Tiled Hallway floor at a house in Brixton, South London. This classic floor had been discovered underneath an old hallway carpet while refurbishment works were being carried out. I went over initially in mid December to survey the floor and talked the owner through a number of similar restorations we had completed in the past. I could see this floor would need a deep clean to remove the years of dirt and also some tiling would needed to be done to tile a section of concrete near the stairs that had been dug out to lay pipe work when central heating had been installed many years prior. She didn’t want to make a commitment at that point so I left her with our quotation so she could think it over. I suspect she had other quotes to review however I’m pleased to say that she decided to give the work to us.

Victorian Tiled Hallway Before Restoration Brixton Victorian Tiled Hallway Before Restoration Brixton

Once we had agreed a date to do the work I started looking around for replacement tiles that would be needed to restore the floor. Unfortunately the octagonal ones are not made anymore and I couldn’t hold of any salvaged ones either. Having been involved in Tile Restoration work for some time now, I have a list of companies and reclamation yards that are usually a good source for these materials. To resolve the problem I sourced square tiles with a similar look and would cut them to the same shape when on site.

Victorian Tiled Hallway Before Restoration Brixton

Cleaning and Repairing a Heavily Soiled Victorian Tiled Floor

I returned after Christmas to start the restoration process which was due to take two to three days. To start the restoration process we applied a strong dilution of Tile Doctor Remove and Go to the floor, allowed it to soak in for ten minutes and then worked it into the tiles using a scrubbing pad fitted to a rotary machine. Remove and Go is a product that removes coatings from tiles including in this case old paint splashes and carpet adhesive. The floor was then rinsed and the now dirty solution extracted using a wet vacuum.

Victorian Tiled Hallway During Restoration
Once this was finished the floor was looking cleaner and the next step was to tackle the concrete area near the stairs where the heating pipes had been buried. The cement had to be carefully chipped away and then refilled with fresh cement but to the level of the original surface so we could lay new tile on top. We use a quick setting compound for this and were able to start relaying and grouting the section with new specially cut tiles later that afternoon.

Victorian Tiled Hallway During Restoration Brixton Victorian Tiled Hallway During Restoration Brixton

Naturally the strip of new tiles were quite noticeable against the old and although the customer was happy I knew I could get a better result by running a very coarse burnishing pad fitted to a heavy buffing machine over the surface. I used a diamond resin hybrid 50 grit pad to take off the top layer of the tiles and then refinished the surface with a 100 and then 200 grit pad. This did the trick and it was impossible to tell the old and new apart.

After this I carried out an acid wash using Tile Doctor Grout Clean-up diluted with four parts water. The purpose of this was to remove any old grout smears and mineral deposits from the floor as well as counteract any possibility of unsightly efflorescence salts rising up through the tile at a later stage. This is quite a common problem with these old floors which don’t have a damp proof coarse and certainly I could see no trace of a DPC when I dug out the cement around the pipe work earlier.

The last step in the cleaning process was to steam the entire floor and then leave it to dry off fully over the New Year break.

Sealing a Victorian Tiled Floor

I returned on the 2nd of January and after inspecting the floor to ensure it was clean and free of damp I began to seal it using Tile Doctor Colour Grow which is an impregnating sealer that soaks into the pores of the tile protecting it from within and enhancing its appearance in the process. Four coats of sealer were needed and as you can see by the final pictures the final results were outstanding.

Victorian Tiled Hallway After Restoration Brixton
Period features such as old Victorian floors add a lot of value to and the customer was over the moon with the transformation and is so happy she chose to have the floor restored rather than covering it back up with carpet.

Victorian Tiled Hallway After Restoration Brixton

Source: Victorian Tile Cleaning and Restoration Service in Brixton

Victorian Tiled Hallway Restoration in North London

This lovely Victorian Tiled Hallway was discovered by a couple during the renovation of their home in Woodford Green which is a suburb of Woodford in North East London. The tiles were covered by a hallway carpet and much of it was obscured by concrete floor leveller. Fortunately just enough of the tile was exposed to give an indication of the Black and White Victorian floor underneath.

After initial investigation and discussion on what was possible, we were invited to quote to restore the floor which I’m pleased to say was accepted. The following pictures show an indication of the process we followed to restore the hallway to its former Victorian glory.

Cleaning Victorian Hallway Tiles

The first step was to remove the concrete floor levelling compound which was done very carefully using small hand tools, detail blades and scrapers. This took a lot of work as we did not want to damage the tiles underneath. You can get a feeling for this from the photographs below where we slowly remove the concrete layer over the floor to reveal the Victorian floor underneath.

Removing Concrete Leveller From Victorian Floor Tiles in Woodford Green Removing Concrete Leveller From Victorian Floor Tiles in Woodford Green

Once the Victorian tiles were all uncovered and the cement had been removed we got a good idea of the condition of the tiles and began a deep clean restorative process. The process began by giving the floor an acid wash with Tile Doctor Grout Clean-Up which was left to dwell on the tile for ten minutes before being scrubbed in to release remaining smears of concrete and grout residue on the tiles.

The resultant soil was then removed with a wet vacuum and the floor then cleaned with Tile Doctor Pro-Clean using a similar technique of leaving it to dwell and then scrubbing it in.

Cleaning Victorian Hallway Floor Tiles in Woodford Green

Once cleaned the soiled cleaning product was removed with a wet vacuum and the floor give an thorough rinse with fresh water which was followed by a steam clean to finalised the process.

Cleaning Victorian Hallway Floor Tiles in Woodford Green

With the floor now deep cleaned we moved on to addressing the three door thresholds which needed to be rebuilt to fix loose and replace broken tiles.

Victorian Hallway Floor Tile Threshold After Cleaning in Woodford Green

Sealing Victorian Hallway Tiles

The tiles were left to dry and set overnight and we returned later to seal them with an initial coat of Tile Doctor Colour Grow, an impregnating seal as a primer before re-grouting. Colour Grow is an impregnator that seeps into the pores of the tile protecting it from within and also enhancing the colours in the tile.

Victorian Hallway Floor Tiles Regrouting in Woodford Green

Once the sealer had dried we moved on to grouting those areas which were repaired the previous day with a matching grout colour and then this was left to set

When the grout was set it was time to finish off the sealing this time using five applications of Tile Doctor Seal & Go to provide a natural sheen finish.

Victorian Tiled Hallway Floor After Full Restoration in Woodford Green

As you can see from the picture, the floor has been fully restored to its original condition and with the correct maintenance; it should last for years to come.


Source: Victorian Tile Cleaning and Restoration Service in London

Restoring an Old Victorian Hallway Floor in Monmouth

This beautiful black & white Victorian tiled hallway was recently discovered hidden under carpet at a house near Monmouth. As well as the years of grime that had become ingrained in the tile, the carpet had been secured with carpet grippers which had been fixed on top of the tiles and the owner was keen to recruit my help in its restoration.

It’s a lovely drive up through the Wye Valley from my base in Caldicot to the town of Monmouth which has a long history that goes back to the Roman times. In fact it’s famous for its “Monnow Bridge” which dates back to medieval times and is the only remaining stone gated bridge of its type left in Britain. Needles to say it has a strong mixture of architecture with many old houses built during Victorian times.

Victorian Floor Before Renovation in Monmouth

Cleaning an Original Victorian Tiled Hallway Floor

The first step in cleaning the floor was to prepare it for cleaning by carefully removing the old carpet grippers and adhesive deposits using a handheld scraper. This was followed by creating a mixture of two powerful cleaning products namely Tile Doctor Remove and Go and NanoTech HBU remover. Remove and Go is a coatings remover designed to strip off old sealers whilst NanoTech HBU is a powerful Heavy Build-Up Remover that uses tiny abrasive particles to clean up tile and stone.

The floor was smothered in the cleaning solution and it was allowed to soak into the tile for about twenty minutes before scrubbing it in. It was not an exceptionally large hallway so a lot of hand scrubbing was required to get the floor as clean as possible. The cleaning solution was rinsed off with water and then extracted using a wet vacuum or wet vac as my colleagues often refer to it.

To finish off the cleaning process I scrubbed a dilution of Tile Doctor Pro-Clean into the grout lines to get them as clean as possible and then gave the floor a final rinse. I need the floor to be dry before sealing so using the wet vac I extracted as much moisture from the floor as possible.

Sealing an Original Victorian Tiled Hallway Floor

I left the floor to dry completely overnight and returned the next day to finish the floor off with a few coats of sealer. On my arrival I started by taking a few reading with a damp meter to ensure the floor was ready to be sealed. Fortunately by efforts with the Wet Vac the night before had paid off and it confirmed the tiles were dry and ready to be sealed.

To do this, I used multiple coats of Tile Doctor Seal and Go which works really well on Victorian Tiles and adds a nice low sheen that brings them up nicely. Naturally the sealer not only improves the way they look it also makes them much easier to clean and will protect them against ingrained dirt and staining.

Victorian Floor After Renovation in Monmouth

I think you will agree this old floor has been transformed and now has a new lease of life.


Source: Victorian Tile Cleaning and Renovation Service in Monmouthshire

External Edwardian Pathway Repaired and Restored in North London

As you can see this Clay Tiled Pathway laid during the Edwardian period at the front of a house in Barnet, North London had suffered over the years and now had many broken and cracked tiles along the path. The concrete foundation had seen some movement in the past leading to a crack forming right across which had either cracked the tile or caused them to become loose.

Edwardian Clay Pathway Barnet Before Cleaning Edwardian Clay Pathway Barnet Before Cleaning

To restore the path to its original condition would require removing all the broken and loose tiles and then relaying with matching replacements and grout giving particular attention to the detailed edging pattern. Fortunately, having done a few of these jobs before I have learned where to find replacements and often keep an eye on salvage yards and ebay.

Edwardian Clay Pathway Barnet Before Cleaning Edwardian Clay Pathway Barnet Before Cleaning

Cleaning and Repairing an Edwardian Clay Tiled Pathway

The first job was to remove ingrained dirt and old coatings by applying a strong dilution of Tile Doctor Remove & Go across the entire length of the pathway. Remove and Go as its name suggests breaks down and strips off the old sealers as well as dislodging ingrained dirt. It was scrubbed in and then rinsed off with water and extracted using a wet vacuum.

Next some of the tiles which had experienced particularly stubborn staining were given an Acid Wash using Tile Doctor Acid Gel which removes old grout smears and mineral salts deposits which is often referred to as efflorescence. Acid Gel neutralises the alkaline salts and once scrubbed in it was removed using the wet vacuum.

Once the dirt and efflorescence had been dealt with, I focused my attention towards the tile repairs starting with the removal of the broken and loose tiles so I could get at the cracked sub-base and repair it. Once the repair had hardened I was able to relay the path using a mixture of exiting and replacement tiles taking care to match the original pattern. Before leaving for the day the tile adhesive had gone off and I was able to grout them in using a matching grout. I had also checked the weather forecast to ensure no rain was forecast that evening.

Sealing an Edwardian Clay Tiled Pathway

The weather held and the following day with a freshly cleaned and repaired path I was able to finish the job by applying two coats of Tile Doctor Colour Grow which really brings out the natural colours in the clay tile. Once the sealer had dried I ran a white buffing pad over the path to give it that final finish before showing it to the owner of the property who I’m happy to report was extremely pleased with the result.

Edwardian Clay Pathway Barnet After Cleaning

I should mention that when choosing a Sealer for an external application it’s important to choose one which is fully breathable and can cope with the wet conditions.


Source: Edwardian Tile Cleaning and Restoration Service in North London

Putting new life into a Victorian Hallway floor in Cheshire

The village of Grappenhall has a long history that goes all the way back to the bronze age and as a result has all periods of architecture including quite a lot of houses with Victorian tiled hallways . This particular floor at a house in the village had been well looked after well by the owner but had now lost its vibrancy, was looking dull and now needed a deep clean and reseal.

Victorian tiles are porous and so need to be sealed to protect them from dirt becoming ingrained in the floor. However, hallway floors get a lot of foot traffic which over time wears down the sealer until it becomes so thin and patchy it’s no longer effective. As a result, you need to regularly top up the sealer or every three to four years it will need to be stripped off and reapplied.

Victorian Tiled Hallway Grapenhall Before Cleaning Victorian Tiled Hallway Grapenhall Before Cleaning

Deep Cleaning the Victorian Tiled Floor

I used clear plastic to protect the wood skirting boards from splashing and then gave the tiles a good scrub with a mixture of Tile Doctor Pro-Clean and Remove and Go to deep clean and strip off any remaining sealers. The cleaning solution was left to soak in for ten minutes before scrubbing it in with a black pad fitted to a heavy buffing machine.

Once the whole area had been scrubbed I rinsed off with water which was then extracted using a wet vacuum. With the floor now clear I was able to inspect it to ensure all the previous sealer and ingrained dirt had been removed. Any areas with stubborn stains were spot treated by reapplying the cleaning concoction I used earlier before leaving the floor to dry off fully overnight.

Sealing the Victorian Tiled Floor

When I returned the next morning my first job was to test the tiles for damp using a damp meter. This is important as damp tiles won’t take the sealer as well as dry tiles, however this time everything was fine.

I then proceeded to seal the Victorian tiles with a single coat of Tile Doctor Colour Grow to enhance the natural colours in the tile before applying a further seven coats of Tile Doctor Seal and Go which leaves a sheen finish and is ideal for Victorian tiles.

Victorian Tiled Hallway Grapenhall After Cleaning Victorian Tiled Hallway Grapenhall After Cleaning

The hallway now looks fantastic and vibrant and then new sealer will protect them from ingrained dirt making them easier to clean and keep them looking good for some time to come.


Source: Victorian Tile Cleaning and Restoration Service in Cheshire

Repairing and Restoring an Edwardian Tiled Hallway in North London

This customer from Islington in North London had an Edwardian Black and White tiled hallway in need of repair and restoring.

Edwardian Hallway Floor Before Tile Cleaning Islington

To restore the lustre of the Edwardian floor tiles the floor would need what was left of the old sealer stripped off, tiles deep cleaned, the replacing of missing and broken tiles and finally applying an impregnating colour restoring products and a protective sealer. You will full details of how this was done below.

Edwardian Hallway Floor Before Tile Cleaning Islington

Cleaning Edwardian Style Tiles

Before starting we covered the skirting, doors and threshold areas with protective tape. Then to remove what was left of the old sealer and clean the floor the area was left to soak in a strong solution of Tile Doctor Remove and Go for about ten minutes. It was then scrubbed into the tile using a slow speed orbital floor machine fitted with a black scrubbing pad and also hand held brushes to get into the corners and other tricky areas.

The now soiled cleaning solution did a good job removing the dirt and old sealer and was rinsed away using water and then extracted with a wet vacuum. The tile and grout was inspected and the process repeated where required before giving the floor a final rinse to remove any trace of cleaning product. It was getting late at this point so the floor was left to dry off thoroughly overnight.

Sealing Edwardian Style Tiles

On our return we first carried out a number of restorative tile repairs using matching Edwardian reclaimed tile replacements primarily to the door thresholds and skirting board edges. Before grouting we applied a single coat of Tile Doctor Colour Grow sealer to the whole floor as this would make any excess grout easier to remove. Colour Grow is also a breathable sealer that impregnates into the pores of the tile protecting it from within and also enhancing the colours in the tile.

We had to leave the floor for another day primarily to allow the grout to dry before returning the next day to complete the sealing process this time using six coats of Tile Doctor Seal and Go which adds a lovely sheen and works really well on Edwardian floor tiles.

Edwardian Hallway Floor After Tile Cleaning Islington

As you can see from the picture, the floor has been restored to its original condition and with the correct maintenance; it should last for years to come.

Edwardian Hallway Floor After Tile Cleaning Islington



Source: Edwardian Tile Cleaning and Maintenance Service in North London

Removing Tar from Edwardian Hallway Tiles in Warwickshire

The owner of this house in Chaplefields near Coventry had bought this property as an investment and was keen to improve its appearance. As part of this work he had lifted the vinyl tiles in the hallway and discovered a lovely Edwardian tiled floor. Unfortunately, whoever had laid the Vinyl tiles had decided to use Tar as an adhesive and this had left a black mess all over the floor.

Edwardian Tiled Floor Covered In Tar Chaplefields Coventry Before Restoration

Realising the potential value an original feature such as this could add to the property he was keen to restore the tiles but not so keen to deal with the Tar, so we were asked to deal with the problem and restore the floor as close to its original condition as possible.

Repairing and Cleaning a Dirty Edwardian Tiled Floor

To get the tiles clean and remove the horrible tar I applied a strong dilution of Tile Doctor Remove and Go, which as its name suggest is great for removing coverings from tiles. I applied the Remove and Go with a mop, left it to soak in for a few minutes and then worked it in using a rotary machine fitted with a black scrubbing pad. The soil was extracted off the floor using a wet and dry vacuum and then the process repeated until I was happy all the tar was gone.

I then gave the tiles an acid wash using Tile Doctor Acid Gel; this serves to break down alkaline mineral deposits such as cement and grout smears, it also counters any efflorescence problems which can be an issue with these old floors where no damp proof membrane has been installed.

Finally, the floor was given a rinse with clean water and a steam clean to remove any trace of cleaning products and to neutralise the tiles in preparation for sealing.

Sealing a Edwardian Tiled Floor

I left the floor to dry off overnight and returned to the property to seal the tiles the next day. To seal the tiles, I used three coats of Tile Doctor Seal and Go which is a water based sealer that leaves a subtle sheen finish and being water based doesn’t leave a smell as it dries. The sealer will provide durable protection going forward preventing dirt from becoming ingrained into the pores of the tile and ensuring it remains easy to clean and keeping its appearance for some time to come.

Edwardian Tiled Floor Covered In Tar Chaplefields Coventry After Restoration

The floor now looks fantastic and gives a great impression when you come into the property which is exactly what the owner wanted.


Source: Edwardian Floor Tile Cleaning and Restoration in Warwickshire

Renovating Old Edwardian Hallway Tiles in Devon

Colyton is a small village in the Coly Valley, which itself is part of Devon’s Area of Outstanding Beauty. As you can imagine, it was very nice to drive through the countryside to reach the village to visit a customer. The customer was keen to restore her Edwardian tiled entranceway and hallway in a classic herringbone pattern, which consists of an arrangement of rectangles.

Parts of the floor had been under carpet for a long time and other areas were covered in at least three layers of thick masonry paint. There was some damage to the floor at thresholds where the carpet grips had been hammered into the floor and a few holes with rawl plugs in scattered the area. This had left the floor looking worse for wear and all in all, there was a lot to be done to restore the tiles back to their original condition – just take a look at the photos below.

Edwardian Hallway Tiles Herringbone Pattern Colyton Before Edwardian Hallway Tiles Herringbone Pattern Colyton Before

Several methods were tried on each area during the initial visit to determine the best way forward including chemicals, diamond pads and heat plus a razor scraper. It was clear a mixture of these methods would be needed to get the best results.

Cleaning an Edwardian Tiled Entranceway and Hallway

On my return, I removed the rawl plugs filled the holes with an epoxy resin in a matching colour. Next I started on giving the tiles a deep and thorough clean to remove not just the copious ingrained dirt, but also the unappealing paint smears.

I did this by applying Tile Doctor Remove and Go, which not only cleans the stone, but also strips away any old sealer. Remove and Go is particularly good for removing most artificial coatings and finishes, adhesives, and paints – and can be used on most unpolished natural stone.

Next, I give the tile and grout an acid rinse with Tile Doctor Grout Clean Up, which is a concentrated phosphoric acid product, to negate any underlying efflorescence and alkaline salt deposits. Efflorescence and salt deposits can be common problems for older, original tiled floors because they often lack a damp proof course.

Having finished cleaning the floor, I gave it a thorough rinse using fresh water to remove any traces of chemicals, before leaving it to dry overnight.

Sealing an Edwardian Tiled Entranceway and Hallway

Returning to the property next day, I ran some quick damp tests to check the floor was ready to be sealed.

To seal the floor, I used a single coat of an impregnating sealer called Colour Grow and followed this up with five coats of Tile Doctor Seal and Go. Both sealers will allow for vapour to rise up through the floor ensuring any damp can rise up through the floor in future which is essential for an old floor like this one which has no damp proof membrane.
The also combine to provide stain resistance surface and a robust, low-sheen finish.

And, with that, the job was done. Two days of work later and the floor is back to looking it best, as you can see in the photos below. Another satisfied client for the Devon Tile Doctor who left the following feedback.

“Very good work,we are very pleased with the result.
Stuart was a very professional hard worker and gave us clear advice on taking care of the floor.“

Edwardian Hallway Tiles Herringbone Pattern Colyton After Edwardian Hallway Tiles Herringbone Pattern Colyton After



Source: Edwardian Floor Tile Cleaning and Renovation Service in Devon

Restoring Geometric Victorian Hallway Tiles Hidden under Carpet in North Devon

Barnstaple in North Devon is known to be one of, if not the oldest boroughs in the whole of the United Kingdom. The area certainly has a rich history and many of the properties built in the 19th century still exist and are in use.

It’s not uncommon for the owners of houses built in this era to discover original Victorian tiled floors and hallways. They’ve usually been covered up at some point in the past, either by carpet or linoleum, but if maintained correctly they can be a real asset to any property.

I recently visited one such customer, who lives in Barnstaple, to restore a recently uncovered Victorian tiled hallway that had been tiled in a geometric pattern. This hallway had been neglected and covered for some time by carpet so the colours had faded and there were patches of carpet underlay firmly embedded in some of the tiles.

The property owner uncovered the floor after seeing a similar one in the entrance hallway of a neighbour and was thrilled with her find. After a bit of scrubbing and cleaning the customer decided to call in professional help after a recommendation for the Tile Doctor Devon from a friend. A home visit was conducted and a test patch was done to show what was possible and to talk through options. A quote was then produced which the customer was happy with and the work was arranged for the following week.

Victorian Tiled Hallway Barnstaple before restoration

Cleaning a Neglected Victorian Tiled Hallway

As the floor was really in quite a bad state, I opted to use Tile Doctor NanoTech HBU as my main cleaning product. HBU stands for ‘Heavy Build-Up’ – and that’s exactly what the product is formulated to tackle: heavy build-up of ingrained dirt and soil. It used nano-sized cleaning particles to penetrate deep into the pores of the stone and get underneath stains to lift them to the surface.

I applied NanoTech HBU to the entire hallway and left it to dwell for several hours, before scrubbing it as thoroughly as possible with a brush fitted to a rotary cleaning machine. The soil that was brought to the surface was subsequently rinsed away with fresh water and the resulting slurry was extracted using a wet vacuum.

Sealing a Victorian Tiled Hallway

Once finished with the cleaning process, I left the floor to dry out completely. This was important as older floors which lack a damp proof membrane can suffer from moisture issues, and these issues can damage the performance of the sealer.

Thankfully there were no problems with drying the floor. I was able to seal the tiles using a colour-enhancing impregnating sealer from our range, known as Tile Doctor Colour Grow. For extra protection – and to provide the finish the customer had requested – I also applied a topical sealer called Tile Doctor Seal and Go. This left the floor with a high-quality, long-lasting satin finish.

A properly sealed floor will be much more resistant to stain as well as easier to clean. As with every job a cleaning and maintenance guide was provided which gives handy tips and do’s and don’ts for the floor and that particular sealer.

The restoration reinstated this great Victorian tiled hallway as the showpiece upon entering the property and the customer was absolutely thrilled. You can see the final result below.

Victorian Tiled Hallway Barnstaple after restoration

The customer was thrilled with the floor and was very surprised at just how well the colour came back to the tiles and provided the following feedback:

“I am so pleased with the service Stuart provided. After the initial quote and patch test I felt under no pressure to ask him to proceed, but I was happy with the quote and he arranged a date convenient to me. I am chuffed with my floor, it looks great. The after care has been great also. Thank you Stuart.”


Source: Victorian Floor Tile Cleaning and Restoration Service in Devon

Original Victorian Tiled Hallway Rebuilt in South Wales

This Victorian tiled hallway floor, located in a property in Blackwood, South Wales, was in a bad way. It was suffering from several broken and missing tiles, and the entire floor looked like it had not experienced a good clean and fresh seal in several years. The property itself dated back to 1905, and it’s very likely that the Victorian tiles are original.

However, the property owner was very hopeful that the hallway could be rejuvenated, so he contacted me to carry out the work. Upon my first inspection of the floor, I could immediately see that a lot of tile replacements would need to be carried out.

I suggested to the customer that I repurpose the tiles that surrounded the matt well at the front of the door to use as replacements for the tiles that were broken and damaged. I would then create a new, larger matt well while using original tiles to fix the damaged areas. It’s a technique I’ve used before so I was confident it would work.

He was happy with this suggestion so I agreed to return later that week to complete the restoration.

Victorian Hallway Floor Blackwood Before Repair

Repairing and Cleaning an Original Victorian Tiled Hallway

My first task was to carefully remove the tiles around the exiting matt well, clean off the cement, and, in some cases, skim the thickness off some tiles so that they would position flat against the adjacent tile. Next, I proceeded to fix these replacement tiles in the areas required.

After completing these repairs, I moved on to cleaning the entire hallway. First, I manually scraped off as much of the paint and cement deposits from the surface of the tiles as possible, before cleaning the floor thoroughly with a mixed solution of three products: Tile Doctor Pro Clean, Tile Doctor NanoTech HBU Remover, and Tile Doctor Remove and Go.

Each of these products serves a different purpose. Pro Clean is reliable and powerful alkaline tile cleaner, while NanoTech HBU is a powerful cleaner which uses nano-sized particles to penetrate the pores of the tile and dissolve ingrained dirt and stains. Remove and Go strips away any old sealers, along with any of the stubborn paint and cement deposits.

The solution was left to dwell on the floor for about half an hour, before I scrubbed it into the stone by hand using a coarse black scrubbing pad. The floor was then rinsed thoroughly, before Tile Doctor Grout Clean-Up was applied using a wire wool pad remove light grout smears (grout haze) and signs of efflorescence.

I then completed the grouting of the floor left it to dry for half an hour before giving it a final wipe with a sponge.

Victorian Hallway Floor Blackwood During Restoration

Sealing a Victorian Tiled Hallway

After leaving the floor to dry out overnight, I returned to the property the following morning. I ran some quick checks for moisture to see if the tiles were ready to be sealed.

Thankfully, the floor proved dry and I could proceed the applying Tile Doctor Seal and Go. This sealer works really well on Victorian tiles and provides a nice subtle sheen finish whilst providing stain resistance.

The customer had initially thought the floor could not be salvaged, but now he will be able to enjoy this fantastic original feature from years to come. It just goes to show that a bit of creativity and hard work really can make a difference.

Victorian Hallway Floor Blackwood After Restoration



Source: Victorian Tile Cleaning and Restoration in South Wales

Removing Chewing Gum from old Victorian Hallway in Knaresborough

The photographs below are of a Victorian Tiled Hallway at a house in the historic market and spa town of Knaresborough. The tiles were actually over a hundred years old and as you can see in a terrible state. As well as looking dull and unloved they were traces of plaster, oil based paint and even chewing gum.

Old Victorian Tiled Floor Before Restoration in Knaresborough Old Victorian Tiled Floor Before Restoration in Knaresborough

Restoring a Victorian Tiled Hallway

The first job was to tackle the chewing gum with a sharp flat metal scraper taking to keep the blade level with the tile and not to scratch the tile. Once this was done the next task was to remove the paint by treating the affected areas with a product called Remove and Go which basically does what it says on the bottle. I find it works best by allowing it to soak into the affected area for about ten minutes before scrubbing it in and then rinsing it off with water.

The next step was to give the whole floor a good deep clean with a strong dilution of Tile Doctor Pro-clean, which deep cleans the tiles without damaging them. Again, you leave the product to soak into the tile before scrubbing it in and then rinsing it off and extracting the now soiled solution with a wet vacuum.

After that we gave the floor an acid rinse using Tile Doctor Acid Gel which removed the plaster and also adds a slight acid tint into the base of tile which helps to eliminate a problem we sometimes get with these old tiles called efflorescence which is where mineral salts rise up through the floor leaving white marks on the surface.

Sealing a Victorian Tiled Hallway

Once cleaned and fully dried a damp test was conducted to confirm the floor was dry before sealing. The customer has requested a satin finish, however we only apply this if there is no immediate damp issues or mineral salts present, if so we use a sealer called Tile Doctor Colour Grow which is fully breathable and soaks into the pores of the tile leaving a matt finish. On this occasion, everything was in normal state so we applied four coats of Tile Doctor Seal and Go which provided the satin finish the customer wanted.

Old Victorian Tiled Floor Atfer Restoration in Knaresborough Old Victorian Tiled Floor Atfer Restoration in Knaresborough

We pretty much through the book at this floor to restore it and I’m sure you will agree the effort was well worth it as the floor now looks brand new.

Last thing to do before leaving the customer was to provide them with some advice on how to clean the floor going forward. On this occasion, I explained that the floor will maintain its appearance as long as the sealer remains intact; now sealers will wear down over time however you can maximise their life by using a PH neutral cleaning product as anything stronger will cause premature erosion. To get them off on the right track I left them with a free 500ml bottle of Tile Doctor Neutral cleaner which is PH neutral and will not damage the sealer.


Source: Victorian Tile Cleaning and Restoration in North West Yorkshire

Deep Cleaning Victorian Hallway Tiles in Middlesex

Apologies in advance but I forgot to take the usual before photograph of this Victorian tiled hallway in Twickenham that I worked on recently. It’s a shame really as it was certainly in need of a good clean and re-seal after years of inadequate maintenance and I’m sure a photo would have helped.

Victorian tiles are porous and do need a sealer to stop dirt becoming ingrained, as once that happens they can be difficult to clean and a Hallway is an especially high traffic area that will see a lot of dirt being tramped in. That activity also wears down the sealer over time so it’s important to keep it topped up.

Cleaning Victorian Tiles

On these tiles, we used a 50:50 combination of Tile Doctor Pro-Clean mixed with Tile Doctor Remove and Go. This combination of products works very well to break down old sealers and also to clean the general soil away from the tile. As usual it was left to soak into the tiles for ten minutes before using a heavy duty scrubbing machine to scrub the floor clean. This achieved a good result and the soil and products were then flushed away using our special flushing tool which fires a jet of water onto the tile whilst vacuuming at the same time (no mess!) to an external tank.

Sealing Victorian Tiles

After allowing the tiles to dry off overnight with some heating on, the floor was ready to accept a new seal the next day. Our customer decided to have a sheen finish so we opted to apply Tile Doctor Seal and Go. These tiles are very porous and so need seven coats to be applied to the floor before it was completely sealed.

Victorian Tiled Hallway After Cleaning in Twickenham

Apologies again for not taking a before photo so you can compare the difference however hopefully you can see how health the floor looks following the deep cleaning and application of a fresh sealer which will ensure future maintenance is a lot easier for the customer.

Victorian Tiled Hallway After Cleaning in Twickenham



Source: Victorian Tile Cleaning and Sealing in Middlesex

Victorian Tile Restoration

You can’t beat a Victorian Tiled Hallway it’s such a practical and obvious choice, unfortunately however this floor at a house in Chester had been neglected over the years and covered up with carpet that had been glued to the tile.

Victorian floor Tiles Chester before cleaning

Restoring Victorian Floor Tiles

To remove the dirt, paint and carpet glue it was necessary to coat the floor in a strong dilution of Tile Doctor Remove and Go which as the name suggests is a powerful coatings remover that’s safe to use on tiles.

The solution was left to soak into the tiles in order to break down the glue and paint etc. before being scrubbed in using a rotary machine fitted with a black pad. This cleaned up most of the problems however there were a few stubborn areas on which we used a steamer to penetrate deep into the pores of the tile and lift out the stains. We then removed the soiled cleaning solution using a wet vacuum and give the floor a really thorough rinse.

Due to the age of the floor and house there was no damp proof installed under the floor and there was concern that even with a breathable sealer damp would become trapped under the tile, so we decided not to seal the tiles which is a shame as sealers do lift the appearance that much more. I think you will agree though the floor looks much improved.

Victorian floor Tiles Chester after cleaning



Source: Restoring Victorian Tiles in Cheshire

Restoring Badly Stained Victorian Tile

This classic Victorian tiled floor in Kingswood Kitchen; Cheshire was quite dirty and in need of a deep clean. Cleaning this type of floor is bread and butter for a Tile Doctor and so I had every confidence we could clean in and then re-seal it without any complications.

Victorian Floor Kingswood Before Cleaning 006 Victorian Floor Kingswood Before Cleaning 005

Cleaning a Stained Victorian Floor

In order to tack the ingrained dirt and I decided the best course of action would be to cover the Victorian Floor tiles with a 50/50 mix of Tile Doctor Pro-Clean and Nano-Tech UltraClean and leave it to work on the tile allowing the cleaner to break down any remaining previous sealer and in-grained dirt.

Victorian Floor Kingswood During Cleaning 007 Victorian Floor Kingswood During Cleaning 008

After about 30 minutes I steam cleaned the whole area multiple times to lift the ingrained dirt and grime out of the floor and then give the floor a thorough rinse removing the soiled solution using a wet vacuum. The floor was quite damp at this stage and needs to be dry to seal so we left it to dry overnight, we also left behind a dehumidifier to assist with the drying process.

Sealing a Victorian Floor

The next day we came back and tested the floor using a damp meter to make sure it was dry. Once we were satisfied we sealed the tiles using five coats of Tile Doctor Seal and Go which is ideal for Victorian tiles as it leaves an attractive low sheen finish, it’s also a water based sealer so there is no smell.

Victorian Floor Kingswood After Cleaning 012 Victorian Floor Kingswood After Cleaning 013



Source: Victorian Tile Restoration in North Cheshire

Replacing Missing Victorian Tiles

This large entrance hall tiled in Victorian black and white floor tiles in London W2 had been quite badly damaged in the past by having a carpet glued and nailed on to it. Many tiles were broken or missing and those missing had been replaced by cement.


Cleaning a Victorian Floor

On the first day of this three day job I removed the cement filling and extracted the nails that remained in the floor. I then stabilised the exposed area with a PVA solution before replacing the missing tiles with replica or salvaged ones to match the floor was swept out and vacuumed to remove all loose debris.

On the second day I cleaned the floor, removing the old carpet glue with Tile Doctor “Remove and Go” which was left to dwell onto the tile for a while to allow it to soak into the tile and break down the adhesive; this was then removed with a wet vacuum. The next step was to clean the tiles using Tile Doctor Pro-Clean which was worked in with a black srubbing pad to scrub the cleaning solution into the tile and finish off the cleaning process, again the soiled solution was removed with a wet vacuum. Normally by now the floor would of have been clean however In this case the levels of soaked-in old glue and ground-in dirt from decades of use were such that the floor also required steaming, scraping and wire brushing with a Spid brass wire brush before a final clean with another round of Pro-Clean and a black buffing pad fitted to a Numatic buffing machine. This had the desired affect and the last step was to wash the floor down with clean water to remove any remaining chemicals etc.

Sealing a Victorian Floor Sealing

After leaving the floor to dry overnight I came back the third day to seal the floor using four coats of Tile Doctor Seal and Go which is ideal for Victorian tiled floors as it leaves a low sheen finish whilst providing excellent stain protection.

Victorian-Tile-After-Cleaning-in-London

As you can see from the ‘before’ and ‘after’ photos the results were impressive and the customer described it as, “looking great”.


Source: Victorian tile restoration in Central London

Victorian Tile Cleaning in Shepperton

Details below of a Victorian tiled floor we did recently in in St Margaret’s, Shepperton. The floor had not been maintained for a while and was in need of a mechanical scrub clean and a new seal, building and renovations have been on-going for some time and so in some areas there was a lot of ground in dust and soil.

Cleaning Victorian Tiles

We set about cleaning the floor using Tile Doctor Pro-Clean which was applied with a mop and left it to dwell on the floor for five minutes in order to give it chance to soak into the tile and get to work on the dirt. The solution was then worked into the floor with the use of a rotary scrubbing machine fitted with a scrubbing pad. The soiled residue was then vacuumed away and the floor was rinsed through, the process was then repeated until we were happy with the overall condition of the tiles.

Twickenham Victorian Floor Before

Sealing Victorian Tiles

Due to moisture being held in the substrate we had to allow seven days for the floor to dry and tests were performed with a damp meter to ensure the floor was ready to accept a sealer. Four coats of Tile Doctor Seal and Go were then applied which is a recommended Sealer for Victorian Tile, offering good stain protection and adding a low sheen to the surface. Sealing the floor also makes cleaning it much easier going forward, it is however a slow process as you have to let each coat dry before applying the next.

Twickenham Victorian Floor After

We can maintain all types of tile, stone and grout servicing the Twickenham and the surrounding areas so please get in touch for a free evaluation of your floor.


Source: Maintaining Victorian Floor tiles in Middlesex
