Damaged Victorian Tiled Hallway Repaired and Restored in Edinburgh

These are a few photos from a Victorian tiled hallway we restored in Edinburgh. The property is close to the beautiful city centre and is in a road with other Victorian properties. The floor was once stunning but was now overdue some love and care to restore it back to its’ former self.

Victorian Tiled Entrance Edinburgh Before Restoration

We went over to the property first to survey the floor and see for ourselves the extent of the work required before quoting for the restoration. The floor was incredibly dirty and there were a number of broken tiles that would need to be replaced or repaired. There are handful of companies where you can source matching tiles but with a floor of this age its not always possible. We discussed with the client the process we would follow to restore the floor which would take three days and agreed a price and date for the work. We also took away with us some of the broken tiles to assist in tracking down matching replacements.

Victorian Tiled Entrance Edinburgh Before Restoration

Restoring a Victorian Tiled Hallway Floor

We arrived on the first day and started by taping up the adjacent woodwork to protect it. The next step was to ensure the floor was completely sound before starting the cleaning process which meant dealing with the loose and broken tiles. The loose and broken tiles were removed and then replaced with new reproduction Victorian tiles that we had managed to source from Original Style. The tiles were cut to fit and then set into the floor with tile adhesive. Unfortunately, we were unable to source a replacement for a broken center pattern tile which had an intricate pattern, so we had to secure this back in place using the two broken pieces. With the tiling work completed there was nothing else we could do so we left to allow the adhesive to set.

Victorian Tiled Entrance Edinburgh Before Restoration

Returning the following day, we began the cleaning process using a set of coarse burnishing pads fitted to a rotary machine. 100, 200 and then a 400-grit burnishing pad was applied in sequence. Then after going over the floor a few times with the pads the floor was rinsed with water which was then extracted with a vet vacuum to remove the fine slurry that was generated. This process ground off the dirt and refined the surface of the tile ensuring the old and new tiles made a perfect match.

The next step was to give the floor an acid wash using Tile Doctor Acid Gel which is scrubbed into the tiles and then rinsed off and extracted as before. This allowed us to get the tiles as clean as possible without the need of any alkaline cleaning products which can cause efflorescence issues later when the floor dries. Efflorescence is a common problem on floors of this age where a damp-proof membrane has not been fitted; moisture rises through the sub floor and tile carrying salts which then get deposited on the surface of the tile as the moisture evaporates. Once complete the floor was left to dry off overnight in readiness for sealing process the next day.

Sealing a Victorian Tiled Hallway Floor

On the final third day we returned to seal the floor testing the moisture level first with a damp meter to ensure the floor was dry. The results were positive, and I was happy that it was within the correct tolerance for the sealer to be effective. To seal the floor, we used Tile Doctor Seal and Go Extra, applying 5 coats and letting each coat dry before applying the next.

Victorian Tiled Entrance Edinburgh After Restoration

The sealer gave enhanced the look of the floor leaving a hardwearing sheen surface which will protect the tiles will also make them easy to clean going forward. This sealer is also fully breathable which is perfect for a floor with no damp-proof membrane in that it won’t trap moisture under the tiles where is could eventually spread to the walls and lead to rising damp.

The client was very happy with the restored floor, the colours were now very vibrant, and the dull entrance hall had been transformed to an inviting space.

Victorian Tiled Entrance Edinburgh After Restoration



Source: Professional Restoration of a Victorian Tiled Hallway in Edinburgh

Removing Plaster, Paint and Glue from a Victorian Tiled Hallway in Kings Lynn

As is often the case in years past and for whatever reason many homeowners covered their decorative Victorian hallway tiles in a variety of products from carpet to laminate flooring. These days the trend has reversed and quite rightly many homeowners now realise the value a tiled floor can bring to a property and look to us to have it restored.

Our client had purchased a property in Norfolk seaport of Kings Lynn and, on lifting the dirty old carpet and decaying underlay in the hallway, discovered a beautiful tiled entrance hall. It was obvious that a previous owner had decided to lay carpet over the tiles as an easy way of hiding the result of careless renovation and decorating which had resulted in a thick coating of plaster, paint, carpet tape glue and various other contaminants which had become firmly stuck to the surface. There were also two small rectangular black and brown tiles missing behind the front door which had been damaged during the removal of some old lead pipes.

Victorian Tiled Hallway Before Cleaning Kings Lynn

This was clearly a job which would need somewhat more than a scrubbing brush and a bottle of Flash!

Cleaning a Victorian tiled floor

Our first job was to remove as much of the solid contaminants as possible by hand with floor scrapers and a steamer which softened the more stubborn lumps. We then applied Tile Doctor Remove & Go which is a powerful alkaline stripper to the whole area, left it to dwell on the surface for twenty minutes and then scrubbed it in using a rotary machine fitted with a black scrubbing pad. The resulting slurry was then power rinsed and extracted away using our Ninja machine which is a high-power industrial vacuum. Any remaining patches where the carpet tape had been stuck down were spot treated using Tile Doctor Nanotech HBU which made short work of the hardened glue.

The result was a clean floor, but the surface still felt slightly rough and pitted, a problem which we resolved using the rotary machine fitted with a 200-grit diamond burnishing pad followed by a 400-grit pad with a little 400 grit honing powder which left the surface smooth, silky and ready for the application of a sealer.

Finally, we acid washed the whole area using Tile Doctor Acid Gel, a slow release product which would neutralise any remaining chemicals, improve new sealer adhesion and inhibit the future production of any efflorescence salts. We had used a fair amount of water during the cleaning process, so we left the floor to dry off thoroughly overnight with assistance from our commercial dehumidifier.

Sealing a Victorian tiled floor

On our return the following day, we discussed the sealer options with the client and recommended using microporous Tile Doctor Colour Grow which is an impregnating sealer that seeps into the pores of the stone protecting it from within. It will provide an excellent fluid resistant seal whilst enhancing the natural colours in the stone, additionally it’s fully breathable thereby enabling any moisture trapped under the floor to rise through the floor and evaporate. This is important on old floors like this where no damp-proof membrane was installed. The sealer was applied with a paint pad in tow coats and allowed to dry for an hour before buffing the floor with a hog’s hair pad to give a rich natural-look sheen finish.

Victorian Tiled Hallway After Cleaning Kings Lynn

The Victorian tiles responded well to the treatments which were completed in two consecutive days. My client was extremely pleased with the results and left the following comment:

“My floor was in poor condition after being buried under carpet as well as many, many years of paint and muck. I enjoyed the time they spent at my home and wouldn’t hesitate to use (or recommend) the Tile Doctor service in the future.”



Source: Victorian Tile Cleaning and Sealing Service in Kings Lynn

Restoring a Carpet Covered Tiled Hallway at a Victorian Property in Glasgow’s West End

I thought you might be interested in these pictures of a tile restoration that we carried out in the hallway of a victorian property in the West End of Glasgow. Glasgow is actually the most populated city in Scotland and the third biggest by population in the whole of the UK so naturally a busy location for us.

The floor had been previously covered in carpet and as a result was stained with adhesive and paint splashes. We popped in to do a site visit, so we could survey the floor and see for ourselves the condition of the floor. Although not in great shape, I was happy that the overall floor was in good physical condition and could be restored with the help the products and methods.

Victorian Hallway Floor Before Cleaning Glasgow West End

I discussed with the client the process involved and the costs to put it right. They were happy to accept my quote and we booked the job in for later in the month. The job would take two days to complete, one day to clean and a further day to seal the floor.

Victorian Hallway Floor Before Cleaning Glasgow West End

Cleaning a Victorian Tiled Hallway Floor

The first job was to clear the floor of the wooden carpet gripper by carefully chipping it off the floor. This took a bit of time and we had to be careful not to damage the floor further.

Next, we started on deep cleaning the floor by applying Tile Doctor Oxy-Gel. This is a strong alkaline based cleaner and degreaser in gel form, its great for when a long dwell time is required to break down dirt, grime, acrylic sealers, stains and oil-based products and waxes.

We left the Oxy-Gel to dwell for twenty to thirty minutes to ensure it got to work on breaking down the layers. It was then worked into the tile using a black scrubbing pad fitted to a rotary machine with the slurry rinsed off the floor and extracted with a wet vacuum. This process was carried out a few times to get the floor as clean as possible could before we gave a final scrub and rinse with Tile Doctor Acid Gel to combat any efflorescence issues that can occur on these old floors that do not have a damp proof membrane.

Sealing a Victorian Tiled Hallway Floor

I returned the following day to seal the floor checking first that it had dried using a damp meter. Once I was satisfied, four coats of Tile Doctor Seal and Go Extra were applied to the tiles to give the sheen finish asked for by the client. This process takes longer that you might think as you have to wait for the first coat to dry before applying the next and naturally this can vary depending on the conditions.

I chose Seal and Go Extra as these Victorian properties were built before the invention of damp-proof membranes so you need to use a fully breathable sealer that will allow dampness to rise through the tile and evaporate. Use of a non-breathable sealer can lead to damp becoming trapped under the floor which can spread into the walls leading to rising damp. The sealer will protect the tiles and make it much easier to clean going forward, additionally it enhances the appearance of the tile leaving a sheen finish which allows the vivid colours to shine through.

Victorian Hallway Floor After Sealing Glasgow West End

The client was very happy with the floor and quite amazed with the before and after shots, they had not expected the results to be as good. They would now be able to easily keep the floor clean and looking good for any visitors.

Victorian Hallway Floor After Cleaning Glasgow West End



Source: Victorian Tile Cleaning and Sealing Service in Glasgow

Removing Old Paint from a Victorian Tiled Hallway in Kettering, Northamptonshire

The customer called me after she had removed the lino in her hallway to discover a traditional Victorian tiled floor hidden underneath. Unfortunately, at some time in the past this floor hadn’t been protected whilst decoration was carried out and had been heavily stained with splashes of paint. Although the customer had tried her best to clean the paint off the floor, she had found it was impossible to remove. She was really keen to restore the floor back to its’ former glory and see the back of the nasty looking lino!

I visited the property in Kettering which is a lovely town in Northamptonshire, approx. 15 miles from Northampton itself. The area is now very popular with commuters with regular trains heading to London St Pancras taking just one hour. As the pictures she had sent me showed the floor needed professional cleaning as no amount of household products would be able to remove the problem areas. I discussed with the customer what we could do to get the floor restored and we agreed a price for the work, scheduling it in for a few weeks later.

Victorian Tiled Hallway Before Cleaning Kettering Victorian Tiled Hallway Before Cleaning Kettering

Deep Cleaning a Victorian Tiled Hallway Floor

To clean the floor, it was first sprayed with a solution of Tile Doctor Remove & Go which was left to dwell for fifteen minutes to help soften the paint. We then used our heavy-duty scrubbing machine with the appropriate attachments to scrub the floor. A little warm water was added to the solution on the floor to help remove the paint as the scrubbing was underway. Once done a wet vacuum was used to remove the slurry generated by the scrubbing process.

This process was repeated several times in the most stubborn areas to ensure the floor was as clean as possible. This action removed around 90% of the paint which was a huge improvement, but more work was required before it would meet my standards.

To further improve the condition of the tiles my next course of action was to apply Tile Doctors 100 and 200-grit burnishing pads to the floor with water to help lubricate. After each pad the find slurry that was generated was extracted off the floor using the wet vacuum. This process reconditions the surface of the Victorian tile and removed the remainder of the paint, it also cleaned the remaining areas that needed further attention leaving the floor spotless. I left the floor to dry overnight and arranged to return the following morning to complete the restoration with the application of a sealer.

Sealing a Victorian Tiled Hallway Floor

The customer wanted the floor to look natural so requested a matt finish sealer, also being an old floor without a damp proof membrane I specified the sealer should be fully breathable so moisture can pass up from the sub floor and not become trapped under the tile where it could cause problems. With these factors in mind we agreed on Tile Doctor Ultra Seal which ticks all these boxes.

As you can see from the after pictures, the restorative cleaning process really did the trick. The colours in the floor were now nice and clear and the floor looked as it should.
The customer was over the moon with the outcome, she had not expected the finish achieved to be as good.

Victorian Tiled Hallway After Cleaning Kettering Victorian Tiled Hallway After Cleaning Kettering

No matter how bad you think the floor is with the use of professional machinery and Tile Doctor products we can restore most floors to a high standard, which certainly in this case exceeded the customers’ expectations.



Source: Victorian Tile Cleaning and Sealing Service in Kettering, Northamptonshire

Relaying and Renovating a Victorian Tiled Hallway in Hale Barns

We were contacted by an architect who was working on the redevelopment of a late Victorian property in Hale Barns, their client wanted to restore the property to its former glory and several internal changes meant reconfiguring the doorways on the ground floor. This in turn would impact the elegant Black and White Victorian tiled hallway floor and the request was for us to lift half the tiled floor and then replace it once the internal changes were complete.

Black White Victorian Hallway Floor Before Cleaning Hale Barns Black White Victorian Hallway Floor Before Restoration Hale Barns

Certainly, an interesting request and one we were happy to quote for. Hale Barns is an effluent part of Cheshire with a mixture of late Victorian and ultra-modern housing popular with footballers, so It’s refreshing to see a period property like this sympathetically restored instead of being demolished.

Lifting and Rebuilding a Victorian Tiled Hallway Floor

The first part of the works involved removing the section of flooring that would be disrupted by the internal changes. Normally we would carefully cut out one tile so we can get a purchase on the remainder from underneath; however the floor had some loose tiles so it simply a question of lifting these then putting a flat plate under the rest and popping them up. I make it sound simple but doing it without damaging a tile takes patience.

Black White Victorian Hallway Floor During Tile Removal Hale Barns Black White Victorian Hallway Floor During Removal Hale Barns

The lifted tiles were stored in buckets containing a 4:1 dilution of Tile Doctor Pro-Clean and water. The tiles were left so soak for a couple of days to soften the adhesives, grout and dirt before being cleaned off and left to dry out.

Once the building work was completed, we were called back into rebuilt the Victorian floor taking into account the new door thresholds. The first job was to level the floor with fast drying self-levelling compound to provide a new sub-base for the tiles. This was left to dry overnight and the next day we started laying the floor back down with fast setting tile adhesive. Once the floor was laid, we left for the day, so it could set overnight.

Black White Victorian Hallway Floor During Restoration Hale Barns Black White Victorian Hallway Floor During Restoration Hale Barns

Lifting and Rebuilding a Victorian Tiled Hallway Floor

Next day we checked the tiles were set before starting to clean with a set of abrasive burnishing pads which attach to a slow speed weighted rotary floor machine. We started with a very coarse 100-grit pad and use water to help lubricate the process, the resulting soil is then rinsed off and removed with a wet vacuum. Using exactly the same process we continue to further refine the tiles by working our way through ever finer grades of pads until we get to 1500-grit. The floor was then washed with Tile Doctor Acid Gel and this is left to soak into the tile before being washed off with water. Giving the floor an acid wash in this fashion helps clean the tile of old mineral deposits and also neutralises any alkaline salts in the floor which could cause problems later on, this is a common issue with old floors more commonly known as efflorescence. The floor was dried using the wet vacuum to remove as much moisture as possible before being left to dry off overnight.

Sealing a Victorian Tiled Floor

The next morning, I finished off the restoration of the floor with the application of a very fine 3000-grit burnishing pad which gave the floor a light sheen. This final pad is applied dry with only a little water sprayed onto the tile using a method we call a ‘Spray Burnish’.

The floor was then checked for moisture with a damp meter to make sure it was dry before sealing. All was well and two coats of Tile Doctor Colour Grow sealer were applied to protect the floor going forward. Colour Grow is a fully breathable impregnating sealer that will enhance the colour of the black tiles and being breathable will cope well with any moisture rising through the floor. Once the sealer had dried fully the floor was buffed with the 3000-grit pad leaving a sheen as requested by the client.

Black White Victorian Hallway Floor After Cleaning Hale Barns Black White Victorian Hallway Floor After Sealing Hale Barns

The result was quite a transformation that was well received by the architect and their client.



Source: Victorian Tile Cleaning and Restoration Service in Hale Barns, East-Cheshire

Removing Carpet Glue from an Old Victorian Tiled Hallway in Sheffield

Detailed below is the restoration of a beautiful Victorian tiled hallway that we completed for a ‘co-housing’ community who had purchased a large house in Nether Edge. Situated three miles south if Sheffield, Brincliffe House was built in 1850 and had been used as NHS offices since the end of the Second World War but had been empty since 2012. Built originally for Herbert Unwin who was the owner of Pond Street Brewery it was now subject to a three-million-pound conversion into fifteen apartments.

Victorian Tiled Hallway Before Restoration Brincliffe House Nether Edge

When we first visited the property to survey the floor, we were shown around the ground floor where they had discovered magnificent Victorian tiled floor. The new owners had no idea the floor was there as the NHS had covered it up decades earlier and glued carpet on top. Being a co-housing community, they were keen to do the restoration themselves however after several unsuccessful attempts to remove the strong carpet adhesive they thought better of it and called us in. We ran several tests and worked out the best way to remove the glue. The floor covered about 70 sqm in total so we knew we had our hands full.

Victorian Tiled Hallway Before Restoration Brincliffe House Nether Edge

Removing Carpet Glue from an Old Victorian Tiled Floor

I’d worked out that the best way to remove the carpet adhesive was a combination of coating remover products and abrasive burnishing pads, these are industrial diamond encrusted pads that are usually used to resurface stone however we find they work equally well on Victorian tiles as well.

Working in small sections the floor was treated with a Tile Doctor 200-grit 17 inch Diamond pad fitted to a rotary floor buffer using water as a lubricant. This stripped off a lot of surface dirt and glue which was then rinsed off with water and extracted with a wet vacuum. Next the floor was coated with a mixture of Tile Doctor Remove & Go and Wax Away, two powerful coating removers that are safe to use on Tile and Stone. The mixture was left to soak into the tiles for about twenty minutes before being scrubbed in with a black scrubbing pad which slowly released the glue and dirt from the pores of the tile. In some areas the glue was so thick we found it necessary to use hand scrapers as well. As before the soil was rinsed off with water and then extracted using a wet vacuum.

Victorian Tiled Hallway During Restoration Brincliffe House Nether Edge

Each section of flooring was inspected and retreated where necessary, then once happy with the result it was given a final rinse with water to remove any trace of cleaning product. After two days of hard work the results were truly amazing, and it was very satisfying to see the floor come back to life section by section.

Victorian Tiled Hallway During Restoration Brincliffe House Nether Edge

Sealing Victorian Hallway Tiles

The community were very happy with the results and thankful I had managed to achieve such an amazing transformation. They were however keen to do as much of the project as they could by themselves, so I advised them on the importance of protecting the tiles with a sealer and left that bit tot the community.

Victorian Tiled Hallway After Restoration Brincliffe House Nether Edge

With regards to sealing my recommendation was to apply a couple of coats of Tile Doctor Colour Grow as it would enhance the red and blue colours in the tiles even further. Also, being fully breathable it would be able to cope with any moisture issues which is important on these old floors which were laid without a damp proof membrane.

Victorian Tiled Hallway After Restoration Brincliffe House Nether Edge



Source: Victorian Tile Cleaning and Restoration Service in Sheffield, South-Yorkshire

Original Craven Dunnill Victorian Tiled Hallway Renovated in Worcestershire

I received an enquiry for a clean and seal on this Victorian tiled floor in Worcester, so having spoken to the customer on the phone I arranged a time to make on-site visit to survey the floor and get a good look at the requirements, so I could advise on the cost.

On inspection I could see that not only was the floor pretty dirty, there was also an area of missing tiles. I managed to trace the tiles to Craven Dunnill a high-quality Victorian floor manufacturer based in nearby Bridgnorth that have been in business since 1872. Thankfully I knew I was able to source some more for them which would match nicely. The owner of the property was delighted to hear that not only would we clean the floor, but we could also source, supply and fit replacement tiles thus making the floor complete again.

Victorian Floor Before Restoration Worcester

After visiting the property, I sent the customer an accurate quote for the repairs and to clean and seal the hallway floor. They were happy with the price and my quote was accepted and a date arranged to complete the work.

Cleaning/Repairing a Victorian Tiled Hallway Floor

On arrival the first step was to set up my equipment including a rotary floor scrubber/polisher, a wet and dry vacuum and my tile cutter.

I started with the floor edges first as they are difficult for floor machines to get into effectively. The process involved spraying the edges with Tile Doctor Remove and Go and then scrubbing it in with a a handheld diamond burnishing block. I then sprayed the rest of the floor with more Remove and Go and left it to dwell for ten minutes. I then proceeded to work the product into the floor with the rotary machine fitted with a black scrubbing pad.

Victorian Tiled Hallway Floor During Cleaning Worcester

The floor was then rinsed with water and the soil extracted using a wet vacuum. My next step was to give the tiles an acid wash by scrubbing Tile Doctor Acid Gel into the floor effectively repeating the previous process. The Tile Doctor Acid Gel is especially effective on Victorian floor tiles to remove mineral salt deposits (efflorescence) and old grout smears. Once I was done the soil was rinsed off as before and extracted with a wet vacuum.

Once I was happy the floor was clean, I moved onto the repairs, carefully measuring and cutting the shapes and fixing the tiles into the gaps with rapid set adhesive. I then grouted the area and left the tiles and floor to dry for the rest of the day and would return the following day to seal.

Victorian Tiled Hallway Floor During Repair Worcester

Sealing a Victorian Tiled Hallway Floor

I returned the next day and after checking the floor was dry with a moisture meter, I started with sealing. The product I used was Tile Doctor Seal and Go Extra, this is a fully breathable sealer with a semi-gloss finish which is ideal for old floors like these that won’t have a damp proof membrane installed. I worked the product into the floor leaving 30 minutes between coats and treated the floor to four coats before I was happy the floor was completely sealed.

Victorian Floor After Restoration Worcester

The customer was very happy with the finished floor and left some great feedback (see below) and has been asked by family and neighbours for our details.

“Very pleased with the result. Mark arrived on time every day and was sure to tidy away after himself, leaving no mess. Our Victorian tiled hallway now has a new lease of life and people are already asking who did it? I would have no hesitation in Recommending Mark.”

Victorian Floor After Restoration Worcester



Source: Victorian Tile Cleaning and Restoration Service in Worcestershire

Restoration and Repair of Old Victorian Hallway Tiled Floor in Sheffield

I received a request to take a look at renovating this old Victorian tiled hallway at a ground floor flat in Sheffield. The home owners had recently bought the property and had uncovered the floor under an old carpet. They wondered if the floor was fixable and worth getting repaired, cleaned and sealed.

Victorian Floor Restoration Sheffield Before

The floor was in quite a serious state with patches of sunken areas which had been covered in a levelling compound. There were many cracked and loose tiles and there were a lot of stains, carpet glue and paint on the tiles. The home owner had done some research into the property and had found out that it was once used as Doctors surgery and the hallway had been the waiting room which would make sense as it had certainly seen a fair amount of wear over the years, especially around the door thresholds.

Victorian Floor Restoration Sheffield Before

Our client wanted the existing floor repairing, cleaning and sealing, ideally without replacing the cracked and sunken tiles. They were very keen to try and restore the floor as an original feature which I’m sure you will appreciate are very sought after. I discussed the work that would be needed and how we would proceed. They accepted the price for the work and worked out a date for the work to start.

Victorian Floor Restoration Sheffield Before

Cleaning/Repairing a Victorian Tiled Hallway Floor

We were able to commence work the following week and started by removing all the self-levelling compound that had been applied to the areas of sunken tiles. The tiles were also removed in these areas and a new sub floor created to lift the floor in-line with the rest of the hallway.

Victorian Floor Restoration Sheffield Chipping Away Self=Leveller Compound

The original tiles were then cleaned up and installed back in place. Nearly all the many loose tiles were removed and re fixed in place, unfortunately a few loose tiles were left as removing these would have caused more damage to the floor.

Victorian Floor Restoration Sheffield During Repair

There were many areas of discoloured and stained tiles so after the fixed areas of damage had been left to set overnight, we returned the next day to start on cleaning the tiles. To get the tiles clean we used a combination of Tile Doctor Remove & Go and Acid Gel agitated with a 17-inch 200 grit diamond burnishing pad fitted to a slow speed rotary floor polisher.

Victorian Floor Restoration Sheffield Cleaning with Acid Gel

Combined this created a powerful cleaner/stripping action that can remove sealers, epoxy grout haze, urethane coatings, synthetic finishes, glue adhesives and paints. The resulting slurry was removed with a wet vacuum and rinsed off thoroughly with water. The immediate result showed a marked improvement and you could now get a real impression of how beautiful the floor actually was.

Sealing a Victorian Tiled Hallway Floor

The floor was left to dry overnight, and we returned the next day to complete the restoration with the application of a sealer. Beforehand he floor was tested with the moisture meter to ensure the it was fully dried. We then sealed the floor with three coats of Tile Doctor Seal & Go Extra which is a full breathable sealer and gives the floor a nice satin finish. It’s important to use a breathable sealer on these old floors where no damp proof membrane has been installed otherwise moisture can become trapped under the floor and will find its way up the walls instead.

Victorian Floor Restoration Sheffield After Sealing with Seal and Go Extra

The floor looked fantastic, the client was very pleased, the natural pattern and beauty had been restored to its’ former glory.

Victorian Hallway Floor Sheffield After Restoration



Source: Victorian Tile Cleaning and Restoration Service in Sheffield, South Yorkshire

Deep an Cleaning Edwardian Mosaic Floor in Abington Park, Northamptonshire

My customer recently got in touch and requested a site visit to look at her hallway floor.
The Edwardian property was situated in the Abington Park part of Northampton which is an area is steeped in history, with the nearby Manor House said to have been the home of William Shakespeare’s daughter Elizabeth Bernard. The house has since been turned into a museum.

As you can see from the photos, the floor which was laid when the house was built over 100 years ago using small square brown and beige mosaic tiles in a repeating. Although in good physical condition for its age the floor was looking a little tired and had lost its lustre and vibrant colour. The hallway also had stained wood panelling on one side which was another original feature and the owner of the property was keen to maintain the period feel.

Edwardian Mosaic Tiled Hallway Floor Before Cleaning Abington Park

I discussed with the customer what we could do to restore the floor, explaining the process, timescale and of course the cost. She was happy to go ahead so we scheduled the work in without delay.

Edwardian Mosaic Tiled Hallway Floor Before Cleaning Abington Park

Cleaning an Edwardian Mosaic Tiled Hallway Floor

In order to protect the wall panels and keep the moisture in the floor to a minimum I decided to keep the use of cleaning products to a minimum. This is always a concern with these old floors which have no damp proof membrane as the use of too much water can lead to efflorescence salts appearing later. With this in mid I decided to clean the floor using Tile Doctor burnishing pads as these pads only require a small amount of water and no products, this would also have the benefit of slightly levelling out the surface of the tiles.

My first course of action was to vacuum the floor to ensure there was no loose debris followed by masking up the bottom of the stairs carpet to protect it. I then started the restoration process by using a coarse 100-grit Tile Doctor burnishing pad attached to a 17” industrial rotary machine and a small amount of water to lubricate the process. The 100-grit pad is quite an aggressive pad which removes deeply imbedded stains and as mentioned before a small amount of unevenness. To remove the resultant slurry the floor was rinsed with a small amount of water which was then extracted using a wet pick up machine. This process was then repeated with a 200-grit burnishing pad to smooth out any scratches and polish the tile ready for sealing.

Although it was a relatively small area, 12 square metres this process took the whole day as we work in small sections at a time. Moving the machine slowly with multiple passes over each area.

Sealing an Edwardian Tiled Hallway Floor

I returned the following day and assessed the floor to ensure we were happy with the result from the previous days cleaning. I also took damp meter readings and was pleased to see they were within normal expectations for a floor of this age. Next, I applied Tile Doctor Colour Grow Sealant which is a breathable sealant that will allow any moisture in the sub floor to rise though the tile. This particular sealer is a colour enhancing sealer that protects and improves the natural colours in the tile and leaves a lovely natural finish. The floor now has a much more even finish and will be much easier for the client to maintain in the future.

Edwardian Mosaic Tiled Hallway Floor After Cleaning Abington Park

The customer was very happy with the results and left the following feedback on the Tile Doctor feedback system.

“Great communication about the work planned and quotation. A super job in bringing my Edwardian mosaic tiled floor back to life. Would highly recommend this service”
Karen M”

Edwardian Mosaic Tiled Hallway Floor After Cleaning Abington Park



Source: Mosaic Tile Cleaning and Sealing Service in Abington Park, Northamptonshire

Restoring a Original Edwardian Tiled Hallway in Harpenden, Hertfordshire

The owners of this property in Harpenden asked us to come and clean and reseal their Edwardian Tiled hallway floor and return it to its’ former glory whilst carrying out a few minor repairs to missing, broken and cracked tiles around the edge.

On visiting the property at this popular commuter town within the St Albans district, it was clear the floor was looking a little neglected and in need of some care and attention. They were keen to retain this feature of their Edwardian property. We discussed what could be done to restore the floor and the client was given a quote and a timescale for the work. They were happy to go ahead.

Edwardian Hallway Before Rebuild Harpenden Edwardian Hallway Before Rebuild Harpenden

Cleaning and Repairing an Edwardian Tiled Hallway Floor

The first step was to give the floor a deep clean with a strong dilution of Tile Doctor Pro-Clean. This product is designed for use on Tile, Stone and Grout and when used in a strong dilution can strip away any old sealers without harming the tile itself. The product is left to dwell on the tiles for short time and then scrubbed in using a rotary brush. We then rinsed with water to remove the slurry produced and using a wet vacuum we removed the residue.

Once this was finished and with the floor looking cleaner the next step was to tackle the cracks in a few of the tiles under the stairs. This is when we discovered that the floor had become loose. When removing some of the broken tiles adjacent to the skirting we discovered a whole section of floor, about 1/3 of sqm had become loose and dropped slightly.

Edwardian Hallway During Rebuild Harpenden Edwardian Hallway During Rebuild Harpenden

The client was concerned with this setback and wasn’t sure what we would be able to do. However, the need not have worried, we have come across this situation before! To tackle the problem, we carefully excavated the area and re built the sub floor below the tiles in concrete. We then levelled the floor in preparation for tiling. Luckily, we were able to salvage the existing tiles and they were individually cleaned using a diamond wet cutter before being re-laid into the original pattern.

Edwardian Hallway During Rebuild Harpenden

Sealing an Edwardian Tiled Hallway Floor

With the original tiles laid back down clean and the flooring rebuilt under the stairs we re-grouted the floor before we were ready to apply a protective sealer. Before doing that however the floor needed to be dry, so we left it to dry off fully overnight.

Returning the following morning, we checked with a moisture meter that the floor was dry, which it was. Firstly, we applied a primer seal using Tile Doctor Colour Grow which is an impregnating sealer to protect the tiles and enhance their colour. Once the first coat of sealer was dry it was followed by five coats of Tile Doctor Seal & Go which adds further protection and leaves a glorious sheen.

Edwardian Hallway After Rebuild Harpenden Edwardian Hallway After Rebuild Harpenden

The floor looks amazing and the client was over the moon with the end result. It far exceeded their expectations particularly after finding an area of the floor had collapsed.

Edwardian Hallway After Rebuild Harpenden



Source: Edwardian Tile Cleaning and Restoration Service in Harpenden, Hertfordshire

Choosing a Sealer for Victorian Tiled Floor near the Swansea Coast

I was called to a property in the Mumbles area of Swansea, one of my favourite places and in fact listed in 2018 Best Places to Live. In the UK report, The Sunday Times listed Mumbles as the best in Wales, so it is always a pleasure to visit this area.

The hallway at the property had a lovely example of a classic Victorian Tiled floor containing a very detailed pattern consisting of expensive blue square and triangular shaped tiles. The tiles were a lovely and unusual pattern and in good physical condition with no cracked or replacement tiles required. It had however, been some time since the floor was last cleaned and sealed and so they contacted me, their local Tile Doctor representative to renovate the floor for them. The owners of the house recognised that it’s well worth preserving original features like Victorian tiled floors as period floors like this are in demand and add value to a property. They were therefore keen to get it back to its’ near original state.

Victorian Hallway Floor Tiles Before Cleaning The Mumbles

Cleaning/Repairing a Victorian Tiled Hallway Floor

To restore the appearance of the tiles I used a 200-Grit diamond encrusted burnishing pad to remove the dirt and restore the condition of the tiles. This is run over the floor using water to lubricate and then rinsed off with water afterwards to remove the soil that is generated. This was then followed up with a 400-Grit pad which cleans and restores the surface which is left roughened after the application of the coarse 200-grit pad. This pad is again applied with water and then the floor rinsed afterwards to remove the soiling and the water is extracted using a wet vacuum.

The next step was to acid rinse the floor using Tile Doctor Acid-Gel, this is an important step for old Victorian tiled floors which have no damp proof membrane. It neutralises any inherent salts in the floor which rise through the tile from evaporation leaving unsightly white deposits on the surface. The acid gel is left to dwell for a short time and then it is scrubbed into the tile with a deck brush and then removed using the wet vacuum, the floor was then given a final rinse to neutralise it before sealing. However, for that to happen I needed the floor to be dry so after cleaning the floor I left it to dry off overnight.

Sealing a Victorian Tiled Hallway Floor

The next day I came back to the house to seal the floor. The floor had dried out nicely due to the fine weather, I quickly did a moisture test to be sure, then I was ready to move on to the sealing process.

The Mumbles area is close to the coast, so for this project I decided to use Tile Doctor Colour Grow which being an impregnating fully breathable sealer would cope better with the salty sea air. Colour Grow is a matt finish sealer that seeps into the tile occupying the small pores and in doing so prevents dirt from becoming ingrained there, it’s also a colour enhancing product that improves the colour in the tile.

After I had finished the floor was left looking restored, fresh and the vibrantly coloured pattern shone through. The client was very happy with the end result.

Victorian Hallway Floor Tiles After Cleaning The Mumbles



Source: Victorian Tile Cleaning and Polishing Service in Mumbles, Swansea

Removing Cement Screed from Victorian Tiles in Bearwood, Birmingham

This customer got in touch with me to see if there was anything I could do to restore a Victorian tiled floor they had discovered under carpet in their hallway. Interestingly they had been told previously that the floor was beyond repair and had been quoted thousands of pounds to have it completely ripped up and replaced.

Victorian Hallway Before Restoration Bearwood Victorian Hallway Before Restoration Bearwood

I visited the property in Bearwood near Smethwick, to take a look and could see that there was a section under a cement screed. The floor was in a truly sorry state, so I could see why the other company were not keen on restoring it. Undeterred I did a test clean to see if I could remove the screed which was encouraging however without removing all the screed it would not be possible to see what condition the tiles underneath were in. I agreed with the customer to order some replacement tiles which were needed along with extra ones just in case. The job would take a few days to allow for cleaning, repairing, drying out and sealing. The client wasn’t too optimistic, but I reassured them we could definitely get a good result.

Victorian Hallway Before Restoration Bearwood

Cleaning and Repairing a Victorian Tiled Hallway

The first day was spent removing the cement screed which was quite thick in parts, so I went down the route of steaming it first to help soften the covering and then carefully scraping it off. This was quite labour intensive, but it did the job. Once the cement was removed I was left with some tiles that were ok but quite a few needed to be replaced.

Victorian Hallway During Restoration Bearwood Victorian Hallway During Restoration Bearwood

There were also two doorways, one that needed completely relaying and one needed part relaying. Some of the tiles needed to be cut to size, there were many tiles that needed resetting and re-grouting along with grout being applied to the new tiles.

Victorian Hallway During Restoration Bearwood

The next day the tiles were deep cleaned with a 50:50 combination of Tile Doctor Pro-Clean mixed with Nanotech HBU which stands for Heavy Build-Up Remover, which was quite appropriate in this case. This cocktail of tile cleaning products was left to dwell on the tiles for a while then worked in with a black scrubbing pad fitted to a weighted rotary machine. The floor was then rinsed off with water and then the soil extracted with a wet vacuum.

My next step was to give the floor and acid wash to remove any old grout smears and neutralise other mineral contaminates such as salts that can get deposited on the surface of the tiles as moisture evaporates as the floor dries. This is always a risk with old floors where no damp proof membrane exists. To do this I applied a dilution of Tile Doctor Grout Clean-Up which is scrubbed into the tiles with a deck brush and then rinsed off the floor with water and a wet vacuum. The floor was then left to dry out for a couple of days.

Sealing a Victorian Tiled Hallway Floor

I returned to seal the floor and after check it had dried sufficiently applied three coats of Tile Doctor Colour Grow sealer. This sealer seeps into the pores of the tile enhancing the colours and leaves a matt finish which the customer had previously specified. The floor was then buffed with a white pad and the customer left with a bottle of Tile Doctor Neutral Tile Cleaner to clean the floor with moving forward.

Victorian Hallway After Restoration Bearwood Victorian Hallway After Restoration Bearwood

The customer was delighted with the results and left the following feedback on the Tile Doctor feedback system.

“Kieron has done a fantastic job of our Victorian hallway tiles. We had been quoted several really high prices by other companies, but Kieron’s quote was a fraction of these. I initially wondered whether this meant the job wouldn’t be as good but after 3 days of solid work the results are fantastic! He managed to transform it to its former glory, a hallway that was partly cemented over, had missing and loose tiles all over the place and was filthy. He definitely does a lot more than just cleaning! We couldn’t be happier with the results!”

Victorian Hallway After Restoration Bearwood



Source: Victorian Tile Cleaning and Restoration Service in Bearwood, Birmingham

Soiled Victorian Hallway Tiles Deep Cleaned in Swansea

This is a great example of a classic Victorian Tiled Hallway and shows just how hard wearing and durable these floors are. The floor had been installed at a house in Swansea what must have been well over a hundred years ago and was now very badly soiled however I knew from experience that with the right techniques and products they can be given a new lease of life.

Victorian Tiled hallway floor before cleaning Swansea

We mainly use diamond burnishing pads on original Victorian tiles these days, the alternative is to use cleaning products however that method tends to use a lot of water and can aggravate an issue known as efflorescence whereby salts from the sub floor are carried up through the tile as moisture evaporates leaving white salt stains on the surface of the floor. This is not a problem with modern floors as they are usually have a damp proof membrane installed under the floor which prevents damp.

Deep Cleaning Victorian Hallway Tiles

To restore the appearance of the Victorian tiles I started with the application of a coarse 200-Grit diamond encrusted burnishing pad which cuts through the dirt and removes surface staining. The pad is run over the tiles using water to lubricate and then the floor rinsed afterwards to remove the soil that is generated. The soil is then extracted off the floor with a wet vacuum. This is then followed up with a 400-Grit pad which cleans and restores the surface which is left roughened after the application of the coarse 200-grit pad, again the pad is applied with water and then the flor rinsed afterwards to remove the soiling and the water is extracted using a wet vacuum.

The next step was to give the floor an acid wash using Tile Doctor Acid Gel, the acid neutralises the alkaline mineral salts in the floor and reduces the chance of efflorescence occurring, After being scrubbed into the floor the gel is rinsed off the floor using water which is then quickly extracted with the wet vacuum.

The floor was left to dry off overnight and I came back the next day to apply the sealer.

Sealing Victorian Floor Tiles

Before starting the sealing process it’s important to check the floor is dry first for which I use a hand-help damp tester. I find it’s a good idea to take readings from various parts of the floor before I start a job so I can establish a normal background level for the floor.

All was well so the floor was sealed using a couple of coats of Tile Doctor Colour Grow which is an impregnating sealer that works by occupying the pores in the clay tile thus preventing dirt from becoming ingrained there. This particular sealer also enhances the natural colours in the tile and is fully breathable which is important in these situations where you need moisture to evaporate through the tile and not become trapped underneath where it could work its way into the walls of the house.

Victorian Tiled hallway floor after cleaning Swansea

It’s worth knowing that if you do experience effluence salts which are more likely in the damp winter weather, then they can be mopped off the floor before they harden without any damage to the sealer itself.



Source: Victorian Tile Cleaning and Renovation Service in Swansea

Renovating a Victorian Tiled Farmhouse Hallway in Clyst Hydon, Devon

The owners of this floor in the hallway of their Mid-Victorian farmhouse in Clyde Hydon just outside of Honiton, in Devon asked me to visit shortly after they had moved in. Whilst ripping out the old carpet throughout the house they had come across this stunning Victorian tiled floor. Honiton is a market town, more well known for its lace making. As it is my home town, it was a very short commute to work for me, so I was able to visit the property quickly and take a look.

Mid Victorian Tiled Farmhouse Hallway Clyst Hydon Before Cleaning

During my visit I took some moisture readings because these old floors will not have had a damp proof membrane installed and if the moisture levels are too high it can restrict when this type of work can be done due to the sealers needing the floor to be dry(ish), in order to cure. I also did a test clean to show the customers what level of cleaning could be achieved and looked at areas of loose tiles to see if any replacement tiles would need to be sourced. I always like to do a test clean as it demonstrates what can be achieved and it also allows me to work out which methods and products work best.

Cleaning and Repairing a Victorian Tiled Hallway Floor

With the customers happy with the quote I returned to complete the work starting by covering the wooden skirting and bottom of the stairs to protect the paint and carpet from splashing. I then applied a strong dilution of Tile Doctor Pro-Clean on to the floor, ensuring even coverage and keeping an eye on the floor to make sure that it didn’t dry out. Pro-Clean is quite a flexible product than can strip off old sealers when applied in a strong dilution.

After a short time, I set to work scrubbing the Pro-Clean into the floor with a 400-grit diamond pad fitted to a rotary floor buffer. I also used 400-grit hand held burnishing block to cover the corners and any edges not reached by my machine. Once I was satisfied that the tiles were as good as they could be I rinsed the floor to remove the now soiled alkaline cleaner before giving the floor an acid wash with Acid Gel to neutralise with any inherent salts in dfdfthe tiles.

Before I left for the day I fixed the loose tiles back in place, re-grouted the areas that I had replaced tiles and left an air mover on the floor to aid in the drying process. I also suggested that the radiators in the hallway were turned on overnight to further aid the drying process. Occasionally these types of floors need to be left for several days to dry but it is worth the wait and the floors can be used in the meantime provided only socks and indoor shoes are used and care is taken not to get the floor dirty.

Sealing a Victorian Tiled Hallway Floor

Upon returning the next day I tested the moisture content of the floor and was pleased to find that it was well within acceptable levels for the application of the sealer that I was planning to use. I quickly checked the floor for areas that I felt may be able to be improved and once satisfied a single coat of Tile Doctor Colour Grow sealer was applied to the floor. Colour Grow is a colour enhancing impregnating sealer that occupies the pores in the tile thus preventing dirt from becoming ingrained there.

Once this was dry it was followed up by applying two further coats of Tile Doctor Seal and Go Extra which is a compatible surface sealer that leaves a nice subtle sheen finish. Both sealers are fully breathable and able to cope with any damp issues that may impact the floor over time.

Mid Victorian Tiled Farmhouse Hallway Clyst Hydon After Cleaning

The customers were thrilled and said that they were going to reinstate the hallway as the main entrance to the farmhouse in order to show it off to all their visitors!



Source: Victorian Tile Cleaning and Restoration Service in Clyst Hydon, Devon

Old Victorian Tiled Hallway Discovered Under Carpet Renovated in Tooting

We were asked by the customer in Tooting, if we could restore this Victorian tiled hallway floor that they had found underneath a carpet while they were refurbishing their property. Interestingly he had already had a quote from another company, but they were unable to identify what type of tile it was. Old floors like these are not for the in-experienced and if you look closely at my website you will see I have published over 60 detailed accounts of tile cleaning and restorations since 2012.

Victorian Tiled Hallway Before Restoration Tooting Victorian Tiled Hallway Before Restoration Tooting

I could see there was a lovely Victorian Tiled floor hiding underneath the paint spots and plaster dust and carried out a test patch to show him what the floor would look like when it was clean. I also showed him pictures of similar floors that we have restored over the years and was able to show the finishes you can achieve from different sealers. Convinced I was the chap for the job he booked me in there and then.

Cleaning a Heavily Soiled Victorian Tiled Floor

Returning on the agreed date we started the cleaning process by pre-wetting the floor with water. This was followed by the application of a strong dilution of Tile Doctor Remove and Go which was left to soak in for approximately ten minutes. This product is designed for the safe removal of old coating such as sealers from Tile, Stone and Grout and I knew it would be ideal for the task. The solution was then scrubbed into the Victorian tile and gout using a rotary machine fitted with a black stripping pad. The scrubbing process released a lot of the stains and dirt from the floor which were then extracted with a wet vacuum. The process was then repeated until all the sections were treated.

The floor was then rinsed with water and the resultant residue extracted using a wet vacuum before treating the tiles to an Acid Wash to neutralise any alkaline salts and remove mineral deposits and old grout smears. This was done by applying Tile Doctor Acid Gel for around fifteen minutes and then removing it with a final rinse.

Cleaning the hallway took up most of the day and I needed the tiles to be dry before the next step of applying a sealer, so after discussing progress with the owner I left for the day and gave the floor three days to dry out.

Sealing a Victorian Tiled Hallway

On our return I first checked the floor with a damp meter to make sure it had dried out thoroughly. All was well, so we proceeded to seal the tiles using Tile Doctor Colour Grow which is an impregnating sealer that leaves a matt finish and soaks into the pores of the tile protecting it from within and enhancing its appearance in the process.

Victorian Tiled Hallway After Restoration Tooting Victorian Tiled Hallway After Restoration Tooting

Four coats of sealer were needed and as you can see by the final pictures the hallway now looks fantastic and needless to say the customer was over the moon with the final results.

Victorian Tiled Hallway After Restoration Tooting



Source: Victorian Tile Cleaning and Sealing Service in South London

Restoring a Victorian Tiled Hallway Covered with Self Levelling Compound in Yorkshire

Our client in Rotherham had decided to install a new floor in their hallway and after removing many layers of old floor coverings discovered a layer of self-levelling compound underneath. After deciding to chip some of this away they discovered what appeared to be an original Victorian tiled floor. Realising that original features like these are very desirable they decided to call in Tile Doctor to see if it could be restored.

Victorian Tiled Hallway Floor Covered in Self-Leveller Before Restoration Victorian Tiled Hallway Before Restoration Rotherham

Being the local agent for Tile Doctor I was asked to look at the floor and quote for doing the work. I could see this was going to take some time to do properly, the floor was quite seriously damaged, a big area of tiles were missing, the tiles around each doorway were heavily damaged and there were quite a few loose and cracked tiles around the edges of the floor. But we were confident this floor could be made to look amazing once again and add the original charm of this hallway back to how it was intended to be.

Victorian Tiled Hallway Before Repair and Restoration Rotherham

Repairing a Victorian Tiled Hallway Floor

The first course of action was to make the tile repairs which included digging out and rebuilding the sub floor in some areas.

Victorian Tiled Hallway During Subfloor Repair Rotherham Victorian Tiled Hallway During Restoration Rotherham

Fortunately, these black and white Victorian Tiles are fairly common, so I was able to source replacements quite easily. There was a lot of areas to cover so this step took a couple of days to complete.

Deep Cleaning a Victorian tiled floor

To get the floor clean we used a slow speed floor polisher fitted with a 200-grit diamond pad. Aided with Tile Doctor Remove and Go it proved to be an effective combination that cut through and removed the self-levelling compound, it also worked a treat at removing paint stains too.

Victorian Tiled Hallway Before Restoration Rotherham Victorian Tiled Hallway During Restoration Rotherham

The next step was to give the floor an acid wash to remove any remaining grime and dirt. To do this we applied Tile Doctor Acid Gel which being in gel form is quite easy to control. After being scrubbed into the floor it was extracted using a wet vacuum and then the floor given a thorough rinse with water to remove any traces of product.

Victorian Tiled Hallway During Acid Washing Rotherham Victorian Tiled Hallway During Acid Washing Rotherham

The wet vacuum was employed again to extract as much moisture from the floor as possible and then left to dry off fully overnight.

Sealing an Old Victorian Hallway Tiles

The next day I returned to seal the floors checking first that the tiles were dry. All was well so I began applying the sealer which in this case was Tile Doctor Colour Grow which is an impregnating sealer that works by soaking into the pores of the tile to prevent dirt from becoming ingrained there.

Victorian Tiled Hallway After Cleaning Rotherham Victorian Tiled Hallway After Restoration Rotherham

The floor was completely transformed over the course of five days and our customer was over the moon with the results calling it her ‘forever floor’.

Victorian Tiled Hallway After Repair Rotherham



Source: Victorian Tile Cleaning and Restoration Service in South Yorkshire

Victorian Hallway Floor Renovated at Old Sheffield Vicarage

Our client had recently moved into this beautiful former vicarage in Sheffield, the hallway had a stunning Victorian tiled floor and there were quarry tiles in two adjoining rooms. The floors hadn’t been maintained properly in quite some time and due to building work in the house they had become very dirty; the Victorian floor also needed some repairs doing as there were areas of loose tiles.

Victorian Hallway Before Cleaning Sheffield

The new owner wanted the floors restoring which in this case meant making some repairs, deep cleaning the tiles and then sealing to protect them from further staining. I quoted for doing the work which was accepted and agreed a date to return and complete the work.

Repairing a Victorian tiled floor

It made sense to start with the tile repairs first, so I inspected the whole floor for loose tiles and carefully removed them. The tiles and floor were then cleaned up to remove the old adhesive and grout.

Victorian Hallway During Tile Repair Sheffield

The tiles were fixed into place using a quick setting adhesive and whilst that was setting I started cleaning the floor, returning to grout the tiles later with a matching grout once the adhesive had set firm.

Victorian Hallway During Tile Repair Sheffield

Deep Cleaning a Victorian tiled floor

To deep clean the floor and remove any old sealers present on the tiles I applied a strong dilution of Tile Doctor Remove and Go. This product works best if you leave it to dwell and soak into the tile for about ten minutes before scrubbing it in. There was a large area to cover so I worked in sections and used a floor polishing machine fitted with a coarse 200 grit burnishing pad to grind off surface dirt and work the product into the tile to release the ingrained dirt. I ran the machine on a slow setting which helps reduce splashing and once the section had been cleaned I rinsed off the soiled cleaning solution with water which was then extracted using a wet vacuum.

Victorian Hallway During Cleaning Sheffield

Once the whole floor was clean I followed up with an Acid Wash which removes old grout smears from the tile and neutralises any efflorescence salts inherent in the tile. Efflorescence is a common problem with old floors where no damp proof membrane has been installed and can result in white salt deposits appearing on the surface on the floor. I used Tile Doctor Acid Gel for this step, being in gel form its easier to manage than other products and used the 200-grit burnishing pad to scrub it in. The slurry was then removed with a wet vacuum and the floor dried as much as possible with air movers leaving it to fully dry off overnight.

Victorian Hallway During Cleaning Sheffield Victorian Hallway During Cleaning Sheffield

Sealing an Old Victorian Hallway Tiles

The next day I returned to seal the floors checking first that the tiles were dry. There are a number of sealers I could have used on the floor, but the owner preferred a matt appearance and I wanted to use a fully breathable sealer to ensure it could cope with moisture rising up through the floor due to the lack of the damp proof membrane.

Victorian Hallway After Cleaning Sheffield Victorian Hallway After Cleaning Sheffield

With these considerations in mind I choose Tile Doctor Colour Grow which is an impregnating sealer that protects the tiles from within by occupying the pores in the clay thereby preventing anything else from becoming ingrained there. The other advantage of Colour Grow is it’s a colour intensifying sealer that improves the colours in the tile.

Victorian Hallway After Cleaning Sheffield

Only two coats of Colour Grow were needed, and I think you will agree the floor now looks very clean and so much more vibrant.

Victorian Hallway After Cleaning Sheffield



Source: Victorian Tile Cleaning and Sealing Service in Sheffield, South Yorkshire

Full Renovation of a Victorian Tiled Hallway in Kidderminster, Worcestershire

The young couple who owned this house was in Kidderminster were expecting their first baby and wanted the original hallway floor repaired and restored in keeping with the Victorian house. Before contacting us, they had spoken with a builder who had said it was beyond repair and recommended ripping it up and laying a new floor. They were aware of the value that original features like floors can add to a property so undeterred they kept looking for a solution and found Tile Doctor.

Victorian Tiled Floor Before Restoration Kidderminster

I am the local agent for Tile Doctor in Worcestershire and specialise in the restoration of old tiled floors so after popping round to take a look I was able to confirm that their builder was wrong and there was no reason why the floor couldn’t be restored. Relieved the floor could be restored they happily asked me to do the work and we arranged a date, it also turned out that he was also a fellow Mod and scooter rider, so we had plenty to talk about.

Victorian Tiled Floor Before Restoration Kidderminster Victorian Tiled Floor Before Restoration Kidderminster

Repairing a Victorian Tiled Hallway Floor

I returned to the property a few weeks later with my tiler and we began the work of carefully inspecting the floor to identify, remove and refit loose tiles. This was followed by repairs to the screed base and then cutting new matching tiles to replace those that were missing. Having worked on old Victorian and Edwardian tiles for some years now I have built up a collection of re-claimed tiles and often scan eBay for them as I know they will come in handy at some point in the future.

The repair process took three days to complete as naturally each tile needs to set in place and can only be grouted in once the adhesive has gone off. It’s also delicate work as anything out of place in the pattern of the floor would be conspicuous obvious.

Cleaning a Victorian Tiled Hallway Floor

On the fourth day the tiling work was complete, and I set about giving the floor a thorough clean starting with the application of Tile Doctor Remove and Go to remove any remnants of sealer, paint splashes from decorating and other marks. The solution was left to soak into the tile and grout for ten minutes before being worked in with a scrubbing pad fitted to a rotary floor buffer running on slow speed. The soiled cleaning solution was rinsed off with water and extracted with a wet vacuum, any stubborn areas were then spot treated until I was happy the floor was clear.

Using the same process, the floor was then treated to an acid wash using Tile Doctor Acid Gel. This served two purposes, first and acid wash will remove any fine grout smears and second the acid will neutralise any efflorescent salts that had built up in the tiles and could cause issue later. This is a common problem with old floors as they don’t have the protection of a damp proof membrane. The floor was then carefully rinsed down with water applied using micro fibre cloths, so it wouldn’t get too damp and then left overnight to dry off fully assisted with a couple of air movers I had left in place.

Sealing a Victorian Tiled Hallway Floor

I returned the next day to seal the tiles checking first that the floor was dry by taking a few moisture readings with a damp tester. The air movers had done the job and I was able to crack on applying numerous coats of sealer which will protect the tile going forward and also enhance its appearance.

My choice of sealer was Tile Doctor Seal and Go Extra which is a fully breathable sealer that can cope with moisture rising through the tiles, it also adds a nice sheen to the tile and works extremely well on clay-based tiles such as these.

Over the course of the five days the floor was transformed, and my customer was over the moon and I was happy to have saved yet another floor.

Victorian Tiled Floor After Restoration Kidderminster Victorian Tiled Floor After Restoration Kidderminster



Source: Victorian Hallway Cleaning and Restoration Service in Kidderminster

Restorative Cleaning of an Edwardian Tiled Hallway in Nottingham

The pictures below detail the restorative clean and seal of a Black & White Edwardian Geometric Tiled Hallway at a residence in West Bridgford near Nottingham. The tiles had previously been covered in carpet trapping years of dirt and soiling into the pores of the tile which were also stained with paint spots and traces of carpet adhesive.

These floors are amazing to look at, and it’s a shame that due to changing fashion trends over the decades, that many became covered with other inappropriate floor coverings. At least in the case the carpet was fixed with glue, I have worked on others before were tiles were smashed in order to secure gripper rods.

Edwardian Black and White Geometric Hall Floor Before Restorative Clean and Seal

I could see a lot of work would be needed to bring it back, however having restored countless number of Victorian and Edwardian tiled floors before I was confident we could achieve a good result and was pleased to get the go ahead to complete the work.

Restoring an Edwardian Tiled Hallway Floor

The first part of the cleaning process was to apply a strong dilution of Tile Doctor Remove & Go coatings remover allowing it to dwell and soak into the tiles and break down the adhesive and paint stains. The solution was then agitated using a black scrubbing pad to help break down the historic-soiling and soften the glue and paint so they could be carefully scraped off. This process generated a lot of soil which was rinsed off and extracted using a wet vacuum.

Old tile installations such as these were never designed to be covered as damp proof membranes were unheard of at the time. Instead the tilers of the day used a breathable lime screed to allow moisture to pass freely from the sub floor. This combined with coal fires of the day, and air movement kept a controlled temperature to ensure moisture didn’t build-up.

Covering these floors stops them from breathing and moisture inevitably can build-up and potentially lead to white salts to be deposited on the surface of the tile as it dries. To avoid this problem, which is known as Efflorescence, the salts need to be counteracted with the application of an acid. To this end my next step was to liberally apply Tile Doctor Acid Gel to the tiles and leave it to dwell for time. This process dissolves the efflorescence salts and also removes any other unwanted deposits such as grout smears from the tile.

The last phase of the cleaning process was to remove the Acid Gel and then rinse with water again to remove any trace of product. The floor was then dried as much as possible with a wet vacuum to remove moisture and then left for a few days to fully dry out.

Sealing an Edwardian Tiled Floor

On our return the floor was checked for dampness using a damp meter in a number of different places. All was well so the floor was then sealed in two stages, starting with an application of Tile Doctor Colour Grow which is an impregnating sealer that improves colour. Once the sealer had dried it was followed with a number of coats of Tile Doctor Seal and Go Extra which works really well on Victorian and Edwardian tiles adding a lovely subtle shine. Both these products are fully breathable which is vitally important where efflorescence is a concern. Otherwise, moisture will build up and causing staining and direct moisture into the supporting walls.

Edwardian Black and White Geometric Hall Floor After Restorative Clean and Seal

Once our Restorative Cleaning & Sealing process is complete you should avoid the use of steam cleaners and strong cleaning products as they can prematurely erode the sealer. Ideally we recommend you maintain the floor with Tile Doctors Neutral Tile Cleaning Solution which is pH neutral once it has been correctly diluted.


Source: Edwardian Tile Cleaning and Sealing Service in West Bridgford, Nottinghamshire

Old Victorian Hallway Covered in Carpet Glue Fully Restored in Brighton

The 19th century was a pivotal period for the Brighton and Hove area of East Sussex. Many of the major attractions were built during the Victorian era, including two of the major piers. Over time, Brighton became not just a very popular destination for day trippers, but also for home makers. Lots of Victorian-style houses were built, complete with Victorian-style tiled floors.

Modern homeowners are increasingly uncovering these original Victorian tiles after decades of being hidden under carpet overlay. Contrary to popular belief, it is very much possible to restore these tiles back to peak condition despite suffering from damage, dirt and staining.

Victorian Tiled Hallway Floor Before Restoration Hove

I recently a house in Brighton to prove just that. The customer’s Victorian tiled hallway floor had been covered by many carpets over the past few decades and so there were many thick glue deposits, along with a heavy build-up of dirt and staining.

Victorian Tiled Hallway Floor Before Restoration Hove

Cleaning an Original Victorian Tiled Hallway

After protecting the woodwork with tape, I set about cleaning the Victorian tiles using a combination of products. One of these was Tile Doctor NanoTech HBU (HBU = Heavy Build-Up Remove), a powerful cleaner which uses nano-sized cleaning particles to penetrate deep into the tile to lift out and dissolve ingrained dirt and stains. I mixed the NanoTech HBU together 50:50 with Tile Doctor Pro-Clean, a reliable alkaline-based cleaner. This cleaning mixture was applied to the hallway floor and then covered with a plastic sheet for a few hours before being scrubbed into the tiles thoroughly with a lot of elbow grease and a specialised scrubbing pad.

Victorian Tiled Hallway Floor During Restoration Hove

A lot of the glue deposits were stubborn and would not respond to the chemical cleaning, so I needed to carefully scrape these off by hand. Once the majority of the glue had been removed I applied a set of diamond-encrusted burnishing pads to remove the top layer to resurface the floor and bring back a lot of the definition in the tile.

Victorian Tiled Hallway Floor During Restoration Hove

Sealing an Original Victorian Tiled Hallway

After completing the cleaning process, I left the floor to dry completely. Giving the tiles enough time to dry is important, especially in older properties which won’t have a damp-proof membrane installed. Even a small amount of excess moisture can cloud the sealer and damage its performance.

Once I was satisfied with the moisture level, I proceeded to seal the tiles using numerous coats of Tile Doctor Seal and Go which is a water based sealer that doesn’t leave a smell as it dries and as well as adding a layer of protection to the tiles give an appealing low-sheen finish.

Victorian Tiled Hallway Floor After Restoration Hove

The client, being of French nationality, said she was “sur la lune” (over the moon) with the result! Look at the photos below to see the transformation – I must say I was quite pleased myself!

Victorian Tiled Hallway Floor After Restoration Hove



Source: Victorian Cleaning and Renovation Service in East Sussex
